Jaguar X-type I (2001-2009) Anti-theft circuit

ACTIVE SECURITY SOUNDER (BEHIND LEFT FRONT WHEELWELL) ANTENNA AUDIO UNIT BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DOOR AJAR SWITCH DOOR LATCH (AT REAR OF LEFT REAR DOOR) DRIVER DOOR LATCH (AT REAR OF DRIVER'S DOOR) DOOR AJAR SWITCH ENGINE CONTROL MODULE (ON RIGHT FRONT SIDE OF ENGINE COMPT) EXTERIOR LIGHTS SYSTEM (TURN SIGNALS) FUSE 10 FUSE 27 FUSE 35 FUSE 43 GRN WIRE GRN/BLK WIRE GRN/ORG WIRE HORNS SYSTEM HOT AT ALL TIMES HOT AT ALL TIMES PASSENGER JUNCTION FUSE BOX (BEHIND LEFT SIDE OF DASH) FUSE 22 HOT IN IGNITION SWITCH INCLINATION SENSOR (AT LEFT REAR OF TRUNK) INSTRUMENT CLUSTER INTRUSION SENSOR KEY-IN SWITCH LEFT REAR ORG/ WIRE ORG/YEL WIRE PASSENGER DOOR AJAR SWITCH DOOR LATCH (AT REAR OF RIGHT FRONT DOOR) PASSIVE SECURITY SOUNDER (AT LEFT FRONT OF VEHICLE) POWER DISTRIBUTION FUSE BOX (ON LEFT SIDE OF ENGINE COMPT) RED WIRE RF MODULE (WAGON) (IN ROOF CONSOLE) RIGHT REAR DOOR AJAR SWITCH DOOR LATCH (AT REAR OF RIGHT REAR DOOR) SECURITY GROUND SENSING SEDAN STARTING/ CHARGING SYSTEM COMPUTER DATA LINES SYSTEM TAIL GLASS AJAR SWITCH TAIL GLASS LATCH (WAGON) (AT TAILGATE) TAIL- GATE AJAR SWITCH TAILGATE LATCH TRUNK TRUNK LOCK AJAR SWITCH MOTOR (AT REAR CENTER OF TRUNK LID) W/ MEMORY W/ POWERED REAR WINDOWS W/ PRINTED CIRCUIT BOARD W/O PRINTED CIRCUIT BOARD ROOF CONSOLE WAGON WAGON SEDAN WHT WIRE WHT/GRN WIRE YEL WIRE YEL/BLU WIRE
