Jaguar X-type I (2001-2009) Manual a/c circuit

AIR CONDITIONING BLOWER RELAY BLK WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/PNK WIRE BLK/RED WIRE BLK/WHT WIRE BLOWER BLOWER SERIES RESISTOR (NEAR BLOWER MOTOR) BLU WIRE BLU/YEL WIRE CLIMATE CONTROL MODULE (BEHIND CENTER OF DASH) COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM DISCHARGE TEMPERATURE SENSOR (ON RIGHT SIDE OF AIR DISTRIBUTION UNIT) EVAPORATOR TEMPERATURE SENSOR (ON RIGHT SIDE OF AIR DISTRIBUTION UNIT) FRESH/ RECIRCULATION FLAP ACTUATOR (ON RIGHT SIDE OF AIR DISTRIBUTION UNIT) FUSE 37 FUSE 39 FUSE 45 FUSE 49 GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT W/ BATTERY SAVER RELAY ENERGIZED HOT W/ PASSENGER JUNCTION FUSE BOX IGNITION RELAY ENERGIZED ORG YEL/ WIRE ORG/ WIRE ORG/GRN WIRE ORG/YEL WIRE PASSENGER JUNCTION FUSE BOX (BEHIND LEFT SIDE OF DASH) RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE STEPPER COILS AIR TEMPERATURE BLEND ACTUATOR STEPPER COILS DEFROST DOOR ACTUATOR (ON RIGHT SIDE OF AIR DISTRIBUTION UNIT) STEPPER COILS PANEL/FLOOR ACTUATOR (ON RIGHT SIDE OF AIR DISTRIBUTION UNIT) WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE

AIR CONDITIONING COMPRESSOR CLUTCH (AT FRONT OF ENGINE) AIR CONDITIONING COMPRESSOR CLUTCH RELAY AIR CONDITIONING PRESSURE SENSOR (ON LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/GRN WIRE BLU/YEL WIRE BRN/GRN WIRE COOLING FAN MODULE (NEAR LEFT SIDE OF RADIATOR) ECT SENSOR (ON FRONT ENGINE VEE) ENGINE CONTROL MODULE (ON RIGHT FRONT SIDE OF ENGINE COMPT) FUSE 16 FUSE 40 FUSE 5 GRN WIRE HOT AT ALL TIMES HOT W/ EMS CONTROL RELAY ENERGIZED HOT W/ TRANSIT ISOLATION RELAY ENERGIZED LEFT COOLING FAN (AT LEFT SIDE OF COOLING PACK) NCA WIRE ORG/GRN WIRE ORG/YEL WIRE POWER DISTRIBUTION FUSE BOX (ON LEFT SIDE OF ENGINE COMPT) RED WIRE RED/GRN WIRE RIGHT COOLING FAN (AT RIGHT SIDE OF COOLING PACK) WHT/BLU WIRE WHT/GRN WIRE
