Jaguar S-type I facelift (2004-2008) Shift interlock circuit

BLK WIRE BLU/YEL WIRE BRN WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM FUSE 15 FUSE 3 GEARSHIFT INTERLOCK SOLENOID GRN WIRE GRN/ORG WIRE HOT AT ALL TIMES HOT IN RUN OR START IGNITION SWITCH J-GATE ASSEMBLY KEY LOCK SOLENOID MODE SWITCH NOT-IN-PARK SWITCH PRIMARY JUNCTION FUSE BOX (BELOW RIGHT "A" PILLAR) REAR POWER DISTRIBUTION FUSE BOX (AT RIGHT SIDE OF TRUNK) RED WIRE WARNING SYSTEM YEL WIRE
