Driver"s 16-way memory seat circuit for Jaguar S-type I facelift (2004-2008)

BLK WIRE BLU WIRE BLU/YEL WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE CUSHION BACK RAISE/ LOWER CUSHION EXTEND CUSHION FRONT RAISE/ LOWER DRIVER LUMBAR PUMP (IN DRIVER SEAT BACK) DRIVER LUMBAR SOLENOIDS (IN DRIVER'S UPPER SEAT BACK) DRIVER SEAT SWITCH PACK FUSE 15 FUSE 18 FUSE 32 GRN WIRE GRN/BLK WIRE HEADREST HOT AT ALL TIMES ORG/ WIRE REAR POWER DISTRIBUTION FUSE BOX (AT RIGHT SIDE OF TRUNK) RED WIRE RED/BLU WIRE RED/WHT WIRE SEAT FORE/AFT SEAT INCLINE/ RECLINE WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

BLK WIRE BLU WIRE BLU/YEL WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER MEMORY SWITCH PACK DRIVER SEAT MODULE (BELOW DRIVER'S SEAT) FUSE 7 GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE HEADREST MOTOR (LEFT FRONT UPPER SEAT BACK) HOT AT ALL TIMES MEMORY 1 MEMORY SET IND MEMORY SET MEMORY 2 ORG/ WIRE ORG/GRN WIRE PRIMARY JUNCTION FUSE BOX (BEHIND RIGHT END OF DASH) RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE SEAT CUSHION EXTEND MOTOR (UNDER RIGHT FRONT SEAT) SEAT CUSHION FRONT RAISE/ LOWER MOTOR (UNDER LEFT FRONT SEAT) SEAT CUSHION REAR RAISE/ LOWER MOTOR (UNDER LEFT FRONT SEAT) SEAT FORE/ AFT MOTOR (UNDER LEFT FRONT SEAT) SEAT INCLINE/ RECLINE MOTOR (LEFT FRONT LOWER SEAT BACK) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
