Instrument illumination circuit for Jaguar S-type I facelift (2004-2008)

AUTOLAMP AUXILIARY LIGHTING SWITCH BLK WIRE BLU WIRE BLU/YEL WIRE BRN/GRN WIRE CIGAR LIGHTER COMPUTER DATA LINES SYSTEM DIP BEAM DRIVER DOOR SWITCH PACK EXIT DELAY 1 EXIT DELAY 2 EXIT DELAY 3 FRONT ELECTRONIC MODULE (AT LEFT "A" PILLAR) FUSE 20 FUSE 33 GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT W/SWITCHED SYSTEM POWER RELAY 2 ENERGIZED INSTRUMENT CLUSTER J GATE ASSEMBLY ROOF CONSOLE LEFT REAR WINDOW SWITCH MAIN LIGHT SWITCH MOOD LAMP OFF ORG/ WIRE ORG/YEL WIRE PASSENGER WINDOW SWITCH PRIMARY JUNCTION FUSE BOX (BELOW RIGHT "A" PILLAR) RIGHT REAR WINDOW SWITCH SIDE LAMPS SWITCH ILLUM. WHT WIRE YEL WIRE

A/CCM (WITH PANEL CONTROL) AUDIO AUDIO UNIT AUXILIARY LIGHTING SWITCH BLK WIRE BLU WIRE CASSETTE CENTER CONSOLE SWITCH PACK ENGINE CONTROL MODULE (AT RIGHT SIDE OF ENG COMPT FIREWALL) FUEL FLAP, TRUNK RELEASE SWITCH PACK GRN WIRE HOT IN ACC OR RUN PRIMARY JUNCTION FUSE BOX (BELOW RIGHT "A" PILLAR) FUSE 27 NCA WIRE SPEED CONTROL STEERING WHEEL LIGHTING SWITCH ILLUM. TELEMATICS DISPLAY WHT WIRE YEL WIRE YEL/GRN WIRE
