Headlamps & fog lamps circuit, without high intensity discharge for Jaguar S-type I facelift (2004-2008)

A/C SYSTEM AUTOLAMP AUXILIARY LIGHTING SWITCH BLK WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/YEL WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DIP DIP BEAM DUAL SOLAR SENSOR (ON TOP CENTER OF DASH) EXIT DELAY 1 EXIT DELAY 2 EXIT DELAY 3 FOGLAMP SWITCHES FRONT ELECTRONIC MODULE (LEFT REAR OF ENG COMPT) FUSE 11 FUSE 20 FUSE 23 FUSE 25 FUSE 9 GRN/BLU WIRE GRN/ORG WIRE GRN/WHT WIRE HAZARD SWITCH, INDICATOR (CENTER CONSOLE SWITCH PACKAGE) HOT AT ALL TIMES HOT W/SWITCHED SYSTEM POWER RELAY 1 ENERGIZED HOT W/SWITCHED SYSTEM POWER RELAY 2 ENERGIZED INSTRUMENT CLUSTER LEFT HEADLAMP UNIT LEFT RIGHT LEFT TURN MAIN MAIN LIGHT SWITCH OFF ORG/ WIRE ORG/YEL WIRE PRIMARY JUNCTION FUSE BOX (BELOW RIGHT "A" PILLAR) REAR FRONT RIGHT HEADLAMP UNIT RIGHT TURN SIDE LAMPS WHT/BLU WIRE YEL WIRE

BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/GRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FOG FRONT FOGLAMP RELAY FRONT POWER DISTRIBUTION FUSE BOX (ON RIGHT FRONT OF ENG COMPT) FUSE 15 FUSE 53 FUSE 57 HOT AT ALL TIMES HOT W/SWITCHED SYSTEM POWER RELAY 3 ENERGIZED HOT W/SWITCHED SYSTEM POWER RELAY 4 ENERGIZED LEFT FRONT FOGLAMP LEFT TAILLAMP UNIT REAR ELECTRONIC MODULE (ON RIGHT REAR OF TRUNK) REAR POWER DISTRIBUTION BOX (ON RIGHT SIDE OF TRUNK) RIGHT FRONT FOGLAMP RIGHT TAILLAMP UNIT TOWING TRAILER TOWING MODULE (AT RIGHT REAR OF TRUNK) (W/ TRAILER TOWING PACKAGE) W/O TRAILER YEL WIRE
