Jaguar S-type I facelift (2004-2008) front bulkhead wiring diagram
This page shows the only wiring diagram for the component.front bulkhead, which is found in the car Jaguar S-type I facelift (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
front bulkhead wiring diagram (1 of 1)
3.0L
4.2L
AIR CONDITIONING SYSTEM ENGINE CONTROLS SYSTEM
ANTI-LOCK BRAKE SYSTEM
BLK WIRE
BLU WIRE
BRN WIRE
BRN/RED WIRE
DIODE 3
EMS CONTROL RELAY
ENGINE CONTROLS SYSTEM
EXCEPT S/C
FROM INERTIA SWITCH (DIAGRAM 4 OF 6)
FROM MEGAFUSE ASSEMBLY (DIAGRAM 1 OF 6)
FRONT BULKHEAD
FRONT POWER DISTRIBUTION FUSE BOX (AT RIGHT FRONT OF ENGINE COMPT)
FUSE 1 TO FRONT POWER DISTRIBUTION FUSE BOX (DIAGRAM 6 OF 6)
FUSE 17
FUSE 18
FUSE 20
FUSE 35 FUSE 19 FUSE 36
FUSE 37
FUSE 38
FUSE 9
GRN WIRE
IGNITION COIL RELAY
INTER- COOLER RELAY
RED WIRE
RELAY
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (5 of 6) -> FRONT BULKHEAD
