Jaguar S-type I (1998-2004) Courtesy lamps circuit

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/WHT WIRE BLK/YEL (OR BLK) WIRE BLK/YEL WIRE BLU WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DOOR AJAR DRIVER DOOR COURTESY LAMP DRIVER DOOR LATCH ASSEMBLY FUSE 20 FUSE 4 FUSE 5 GENERAL ELECTRONIC CONTROL MODULE (BELOW LEFT "A" PILLAR) GLOVE BOX LAMP) GRN WIRE GRY WIRE GRY/PPL WIRE GRY/WHT WIRE HOT AT ALL TIMES INSTRUMENT ILLUMINATION CIRCUIT (DIMMER SWITCH) INSTRUMENT PACK J/C LEFT FASCIA LAMP LEFT FRONT MAP LAMP RIGHT FRONT MAP LAMP LEFT FRONT MAP LAMP SWITCH RIGHT FRONT MAP LAMP SWITCH LEFT REAR DOOR LATCH ASSEMBLY LEFT REAR MAP LAMP LEFT SUN- VISOR LAMP, GARAGE DOOR OPENER LEFT TRUNK LAMP MASTER INTERIOR LIGHTING SWITCH ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/GRN WIRE ORG/WHT WIRE ORG/YEL WIRE PASSENGER DOOR LATCH ASSEMBLY PRIMARY JUNCTION BOX (BELOW RIGHT "A" PILLAR) REAR ELECTRONIC CONTROL MODULE (ON RIGHT REAR OF TRUNK) REAR POWER DISTRIBUTION BOX (ON RIGHT SIDE OF TRUNK) RIGHT FASCIA LAMP RIGHT REAR DOOR LATCH ASSEMBLY RIGHT REAR MAP LAMP PASS- ENGER DOOR COURTESY LAMP RIGHT SUN- VISOR LAMP RIGHT TRUNK LAMP ROOF CONSOLE SWITCH PACK SECONDARY JUNCTION BOX (BELOW LEFT "A" PILLAR) TRUNK SWITCH WHT WIRE WHT/BLK WIRE WHT/BLU WIRE
