Jaguar S-type I (1998-2004) Back-up lamps circuit

10 17 10 17 (W/M/T) (W/M/T) (W/A/T) (W/A/T) BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM FUSE 2 FUSE 20 FUSE 4 FUSE 6 FUSE 7 GRN/BLK WIRE GRN/ORG WIRE GRN/WHT WIRE GRY WIRE GRY/PPL WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT IN RUN OR START HOT W/SWITCHED SYSTEM POWER RELAY 3 ENERGIZED HOT W/SWITCHED SYSTEM POWER RELAY 4 ENERGIZED INERTIA SWITCH (BELOW LEFT "A" PILLAR) J/C LEFT TAILLAMP UNIT NAVIGATION SYSTEM (PARKING AID CONTROL MODULE) ORG/BLK WIRE ORG/BLU WIRE ORG/YEL WIRE POWERTRAIN CONTROL MODULE (PCM) (ON RIGHT REAR OF ENGINE COMPT) PRIMARY JUNCTION BOX (BELOW RIGHT "A" PILLAR) REAR ELECTRONIC CONTROL MODULE (ON RIGHT REAR OF TRUNK) REAR POWER DISTRIBUTION BOX (ON RIGHT SIDE OF TRUNK) REVERSE REVERSE SWITCH (ON LEFT SIDE OF TRANSMISSION) RIGHT TAILLAMP UNIT TRAILER TOWING MODULE (W/ TRAILER TOWING PACKAGE) TRANSMISSION RANGE SENSOR (NEAR TRANSMISSION SELECTOR SHAFT) WHT/BLU WIRE WHT/PPL WIRE WHT/RED WIRE YEL/GRN WIRE
