Rear differential lock circuit for Jaguar F-type I facelift (2016-2019)
Rear differential lock circuit
AUXILIARY JUNCTION BOX
BLK/GRN WIRE
BLU/BRN WIRE
BLU/WHT WIRE
CENTRAL JUNCTION BOX
CLUTCH ACTUATION MOTOR
COMPUTER DATA LINES SYSTEM
DIFFERENTIAL OIL TEMPERATURE SENSOR
FUSE 22
FUSIBLE LINK 33
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/YEL WIRE
HALL SENS GND
HALL SENS SIG-A
HALL SENS SIG-B
HALL SENS-PWR
HOT AT ALL TIMES
HOT W/ IGNITION RELAY ENERGIZED
HS CAN HI
HS CAN LO
IGN
MOT-
MOTOR POSITION SENSOR
MOTOR TEMPERATURE SENSOR
PPL/BRN WIRE
PPL/ORG WIRE
REAR DIFFERENTIAL ACTUATOR (ON REAR DIFFERENTIAL ASSEMBLY)
REAR DIFFERENTIAL CONTROL MODULE
RED WIRE
YEL/BLU WIRE
YEL/GRN WIRE
