Heated steering wheel circuit for Jaguar F-type I facelift (2016-2019)
Heated steering wheel circuit
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/RED WIRE
CENTRAL JUNCTION BOX
CLOCK- SPRING
FUSE 20
FUSE 51
GRN WIRE
HEATER ELEMENT
HOT AT ALL TIMES
HOT W/ IGNITION RELAY ENERGIZED
IGN
LEFT STEERING WHEEL SWITCHPACK
LIN
LOGIC GND
NTC SENSOR
NTC-
PPL
PPL LED
PWR
RED WIRE
RIGHT STEERING WHEEL SWITCHPACK
STEERING WHEEL HEATER
STEERING WHEEL HEATER CONTROL MODULE
SWITCH
SWITCH PPL LED
WHT WIRE
YEL/PPL WIRE
