Electrochromic mirror circuit for Jaguar F-type I facelift (2016-2019)
Electrochromic mirror circuit
AUXILIARY JUNCTION BOX (LEFT KICK PANEL)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
EC RTN
EC SUPPLY
EC+
FUSE 21
FUSE 29
GRN/WHT WIRE
HOT W/ DEF MODULES CONTROL RELAY ENERGIZED
HOT W/ EXTENDED IGNITION RELAY ENERGIZED
HS CH CAN H
HS CH CAN L
LEFT DOOR MIRROR
LH MTR VBATT
REAR VIEW MIRROR)
REVERSE
RIGHT DOOR MIRROR
W/ START/ STOP SYSTEM
W/O START STOP SYSTEM
