Blind spot monitoring circuit for Jaguar F-type I facelift (2016-2019)
Blind spot monitoring circuit
AUXILIARY JUNCTION BOX
BLK WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/GRY WIRE
COMPUTER DATA LINES SYSTEM
FUSE 21
FUSE 29
HOT W/ DEF MODULES CONTROL RELAY ENERGIZED
HOT W/ EXTENDED IGNITION RELAY ENERGIZED
IGN
LEFT BLIND SPOT MONITORING MODULE
LEFT DOOR MIRROR
LEFT FRONT DOOR MODULE
MIRROR
MIRROR GND
MS CAN-H
MS CAN-L
PPL/BRN WIRE
PV CAN HI
PV CAN LO
RIGHT BLIND SPOT MONITORING MODULE
RIGHT DOOR MIRROR
RIGHT FRONT DOOR MODULE
STATUS
W/ START/ STOP SYSTEM
W/O START STOP SYSTEM
WARNING ALERT
WHT/GRN WIRE
YEL/GRN WIRE
