Driver"s memory seat circuit, 8-way for Jaguar F-type I facelift (2016-2019)

AUXILIARY JUNCTION BOX BLK WIRE BLK/GRY WIRE BLU/GRN WIRE BOLSTER DEFLATE VALVE BOLSTER INFLATE VALVE BRN/BLU WIRE BRN/GRN WIRE BRN/PPL WIRE CAAA CAAB COMPUTER DATA LINES SYSTEM FUSE 12 GRN/BRN WIRE GRN/ORG WIRE GRN/WHT WIRE GRY WIRE GRY/ORG WIRE GRY/PPL WIRE HALL SENS GND 1 HALL SENS GND 2 HEIGHT SENS HOT W/ COMFORT RELAY ENERGIZED LEFT FRONT SEAT MODULE (UNDER LEFT FRONT SEAT) LEFT LUMBAR PUMP LEFT LUMBAR VALVE BLOCK LEFT SEAT BOLSTER SOLENOID LEFT SEAT MEMORY SWITCHPACK LIN LUMBAR HI 1 LUMBAR HI 2 LUMBAR LO 1 LUMBAR LO 2 LUMBAR PUMP FEED MS CAN-H MS CAN-L POWER DISTRIBUTION SYSTEM PPL/GRN WIRE SLIDE SENS SQUAB HALL SENS TILT SENS V BATT WHT/GRN WIRE YEL WIRE YEL/ORG WIRE YEL/PPL WIRE

BLK/GRY WIRE BLU/GRN WIRE BLU/WHT WIRE BRN/BLU WIRE BRN/RED WIRE CENTRAL JUNCTION BOX FUSE 42 FUSE 46 GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/WHT WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/YEL WIRE HEIGHT DOWN HEIGHT UP HOT AT ALL TIMES LEFT FRONT SEAT MODULE (UNDER LEFT FRONT SEAT) LEFT SEAT BACK RECLINE MOTOR LEFT SEAT FORWARD/REARWARD MOTOR LEFT SEAT HEIGHT MOTOR LEFT SEAT TILT MOTOR LOGIC FEED LOGIC GND POWER FEED 1 POWER FEED 2 POWER GND POWER GND 2 PPL/GRY WIRE PPL/ORG WIRE SLIDE FORWARD SLIDE REARWARD SQUAB INCLINE SQUAB RECLINE TILT DOWN TILT UP WHT/GRN WIRE YEL/ORG WIRE YEL/PPL WIRE YEL/RED WIRE
