Electronic power steering circuit for Jaguar F-type I facelift (2016-2019)

Electronic power steering circuit

Get access

BLK WIRE BLU WIRE BLU/GRN WIRE BLU/RED WIRE CABLE JUNCTION STUD CENTRAL JUNCTION BOX COMPUTER DATA LINES SYSTEM FUSE 6 FUSIBLE LINK 3 HOT AT ALL TIMES HOT W/ IGNITION RELAY ENERGIZED HS CAN-H HS CAN-L IGN POWER STEERING CONTROL MODULE RIGHT ENGINE JUNCTION BOX VBATT WHT/BLU WIRE
