Rear defogger & heated mirrors circuit for Jaguar F-type I facelift (2016-2019)
Rear defogger & heated mirrors circuit
BLK WIRE
BLK/PPL WIRE
BLK/YEL WIRE
BODY CONTROL MODULE (BCM)
BRN/BLU WIRE
CENTRAL JUNCTION BOX
COMPUTER DATA LINES SYSTEM
COUPE
FUSE 15
FUSE 28
FUSE 32
GRN/RED WIRE
HEATED REAR WINDOW ELEMENT
HOT AT ALL TIMES
LEFT DOOR MIRROR
LEFT FRONT DOOR MODULE
MIRROR GND
MIRROR HTR
MS CAN-H
MS CAN-L
PPL/RED WIRE
REAR SCREEN HEATED RELAY
RIGHT DOOR MIRROR
RIGHT FRONT DOOR MODULE
VBATT
