Heated windshield circuit for Jaguar F-type I facelift (2016-2019)
Heated windshield circuit
AUTOMATIC TEMPERATURE CONTROL MODULE
AUXILIARY JUNCTION BOX
BATTERY JUNCTION BOX
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
CAN L
CENTRAL JUNCTION BOX
COMPUTER DATA LINES SYSTEM
FRONT SCREEN HEATED RELAY
FUSIBLE LINK 1
FUSIBLE LINK 4
FUSIBLE LINK 5
GRY/PPL WIRE
HFS RLY
HOT AT ALL TIMES
LEFT ENGINE JUNCTION BOX
LEFT WINDSHIELD HEATER
MS CAN HI OUT
MS CAN LO OUT
ORG/ WIRE
POWER DISTRIBUTION SYSTEM
PPL
PPL/ PPL/ PPL/
PPL/GRN WIRE
PPL/ORG WIRE
RED WIRE
RIGHT END OF DASH)
RIGHT WINDSHIELD HEATER
YEL WIRE
YEL/ORG WIRE
YEL/PPL WIRE
