Jaguar F-type I (2013-2017) Charging circuit, w/o start-stop system

BATTERY BATTERY JUNCTION BOX BATTERY MONITORING SYSTEM MODULE BLK WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/ORG WIRE BODY CONTROL MODULE CENTRAL JUNCTION BOX (LOWER RIGHT SIDE OF DASH) COMPUTER DATA LINES SYSTEM FUSIBLE LINK 12 FUSIBLE LINK 5 GATEWAY MODULE GENERATOR GRY WIRE HS CAN-H HS CAN-L INSTRUMENT CLUSTER LIN LIN 3 MON QUIESCENT CURRENT CONTROL MODULE RED WIRE STARTER MOTOR UNDER BODY BUSBAR WHT WIRE WHT/BLU WIRE
