Car Wiring Diagrams for Heated windshield circuit for Jaguar F-type I (2013-2017)

AUXILIARY JUNCTION BOX BATTERY JUNCTION BOX BLK WIRE BLU WIRE BODY CONTROL MODULE BRN WIRE CAN L CENTRAL JUNCTION BOX CLIMATE CONTROL MODULE COMPUTER DATA LINES SYSTEM FRONT SCREEN HEATED RELAY FUSIBLE LINK 1 FUSIBLE LINK 4 FUSIBLE LINK 5 GRY/ORG WIRE HFS RLY HOT AT ALL TIMES LEFT ENGINE JUNCTION BOX (EJB) LEFT WINDSHIELD HEATER MS CAN HI OUT MS CAN LO OUT ORG/ WIRE PPL PPL/ORG WIRE RED WIRE RIGHT WINDSHIELD HEATER YEL WIRE
