Jaguar F-type I (2013-2017) Body control modules circuit

ALARM LED AMBIENT LIGHTS-BLUE AMBIENT LIGHTS-RED WIRE ANTI-THEFT SYSTEM ANTI-THEFT SYSTEM COMPUTER DATA LINES SYSTEM AUX SW RTN BATTERY JUNCTION BOX BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) BONNET AJAR SW BOOT AJAR BOOT LAMP POWER BOOT REL MOTOR BRAKE DIAG SW BRAKE FLUID LEVEL SW BRAKE PAD WEAR BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/PPL WIRE BRN/WHT WIRE BRN/YEL WIRE CENTRAL JUNCTION BOX (LOWER RIGHT SIDE OF DASH) COLUMN ADJ POT V-REF COLUMN ADJT SWITCH COLUMN M'MENT MODE SEL COLUMN MOTOR DOWN-OUT COLUMN MOTOR UP-IN COLUMN MOVMENT SW RTN COLUMN POT ADJ RAKE COLUMN POT ADJ REACH COMFORT RLY HSD COMPUTER DATA LINES SYSTEM COOLANT LEVEL SW CORNERING LIGHT LH CORNERING LIGHT RH CRANK REQUEST DEFOGGER SYSTEM DI INDICATOR SW DIP BEAM LH DIP BEAM RH DOOR LOCKS SYSTEM DOOR LOCKS SYSTEM INSTRUMENT CLUSTER SYSTEM DOOR LOCKS, TRUNK, TAILGATE, FUEL DOORS SYSTEMS DRIV GLASS SHORT DROP DRL SIG RH ELECTRONIC GND ELECTRONIC POWER STEERING SYSTEM ELECTRONIC SUSPENSION SYSTEM EMS EWU ENGINE CONTROLS SYSTEM ESCL PWR EXIT DELAY SW EXT BOOT REL SW EXTERIOR LIGHTS, INTERIOR LIGHTS, HEADLIGHTS SYSTEMS F/PUMP RLY LSD FD AJAR FERRITE CORE FLICK WIPE SW FOG SIGNAL FP AJAR FRONT RES LOW FUEL SENS EJ FUEL SENS PUMP FUEL TANK SENDER GND FUSIBLE LINK 3 FUSIBLE LINK 4 FUSIBLE LINK 5 FUSIBLE LINK 8 GBOX LATCH GBOX REL SW GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/PPL WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/PPL WIRE GRY/RED WIRE GRY/YEL WIRE HAZARD SW HAZARD SW ILLUM HEADLIGHTS SYSTEM HEARTBEAT ILLUMINATION HFS RLY HORN RLY HORNS SYSTEM HOT AT ALL TIMES HS CAN-H HS CAN-L I BRAKE SW I ENS INSTRUMENT CLUSTER SYSTEM INT MASTER LIGHT SW INTERIOR LIGHT) INTERMITTENT WIPE SW LH DI REAR LH DRL SUPPLY LH FRONT INDICATOR LH STOP LAMP LIGHTING DIMMER MAIN BEAM LH MAIN BEAM RH MAIN FLASH SW MASTER LIGHT SW MASTER LOCK SW MASTER UNLOCK SW MASTER WIPE MEMORY SYSTEMS MS CAN-H MS CAN-L O CHMSL ORG/ WIRE P/N SIGNAL PASS GLASS SHORT DROP PASSIVE SOUNDER PE TG REL TO KVM POS/SM SIG LH POWER DISTRIBUTION SYSTEM POWER WASH L RLY PPL PPL/BRN WIRE PPL/GRN WIRE PPL/GRY WIRE PPL/ORG WIRE PPL/WHT WIRE PWR GND RAKE SOLENOID REACH SOLENOID REAR FOG LH REAR WASHER PUMP RLY RF RX COMM RH DI REAR RH FRONT IND RH REAR POS LAMPS RH STOP LAMP SCREENWASH LEVEL LOW SECOND BOOT REL SW SOFT CLOSE TRIGGER SWITCH SP ISO LSD STARTING/CHARGING SYSTEM STOP START SW GND SUPPLEMENTAL RESTRAINTS SYSTEM SUPPLEMENTAL RESTRAINTS, ENGINE CONTROLS SYSTEMS SVPAS OUTPUT SVPAS RTN SWITCH ILLUM. TPMS INITIATOR LF(1)+ TPMS INITIATOR LF(1)- TRANSIT RELAY TPMS INITIATOR LR(4)+ TPMS INITIATOR RF(2)- TPMS INITIATOR RR(3)+ HSD TPMS INITIATOR RR(3)- TRIP RESET SW TRUNK, TAILGATE, FUEL DOORS SYSTEM WARNING SYSTEMS WASHER SW WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE WHT/PPL WIRE WIPER PARK WIPER RLY FAST/SLOW WIPER RLY ON/OFF WIPER STALK GND WIPER/WASHER SYSTEM WIPER/WASHER SYSTEM INSTRUMENT CLUSTER SYSTEM YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/PPL WIRE
