Jaguar F-type I (2013-2017) stowage compartment accessory socket Wiring diagrams

3.0L 4-WAY 8-WAY 5.0L 8 WAY BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLK/WHT WIRE CAPACITOR CENTRAL JUNCTION BOX CLIMATE CONTROL MODULE CLOCK- SPRING FRONT BLOWER MOTOR CONTROL MODULE FRONT OVERHEAD CONSOLE HEATER STEERING WHEEL IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 IGNITION COIL 5 IGNITION COIL 6 LEFT FRONT SEAT MODULE LEFT HEATED SEAT MODULE LEFT LUMBAR PUMP LEFT SEAT BACKREST HEATER LEFT SEAT BOLSTER SOLENOID NCA WIRE OCCUPANT CLASSIFICATION SENSOR CONTROL MODULE RAIN/LIGHT SENSOR REAR VIEW MIRROR) RF RECEIVER RIGHT FRONT SEAT MODULE RIGHT HEATED SEAT MODULE RIGHT LUMBAR PUMP RIGHT SEAT BACKREST HEATER RIGHT SEAT BOLSTER SOLENOID RIGHT STEERING WHEEL SWITCHPACK SEATBELT TENSION SENSOR STOWAGE COMPARTMENT ACCESSORY SOCKET

4-WAY 8-WAY ACCESSORY SOCKET RELAY ACTIVE EXHAUST RELAY BLK WIRE BLK/BLU WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/RED WIRE CIGAR LIGHTER RELAY CLOCK- SPRING FERRITE CORE FROM BATTERY JUNCTION BOX (DIAGRAM 1 OF 7) FRONT WASH PUMP RELAY FUSE 28 FUSE 38 FUSE 4 FUSE 40 FUSE 42 FUSE 43 FUSE 44 FUSE 45 FUSE 46 FUSE 47 FUSE 51 FUSE 52 FUSE 53 FUSE 55 FUSE 61 FUSE 62 FUSE 63 FUSE 64 FUSE 65 FUSE 66 FUSE 67 FUSE 68 FUSE 69 GATEWAY MODULE GRN/RED WIRE GRN/WHT WIRE GRY/BRN WIRE GRY/RED WIRE IMMOBILIZER ANTENNA UNIT LEFT FRONT SEAT MODULE RED WIRE RIGHT FRONT DOOR MODULE RIGHT FRONT SEAT MODULE RIGHT STEERING WHEEL SWITCHPACK STOWAGE COMPARTMENT ACCESSORY SOCKET TRAILER SOCKET RELAY YEL/RED WIRE
