Car Wiring Diagrams for Heated seats circuit for Jaguar F-Pace I (2016-2020)

BLK WIRE BLU/BRN WIRE BRN WIRE BRN/PPL WIRE CENTRAL JUNCTION BOX COMPUTER DATA LINES SYSTEM DRIVER HEATED SEAT MODULE GRN WIRE GRN/PPL WIRE GRY WIRE GRY/ORG WIRE GRY/PPL WIRE HEATED/ CLIMATE SEAT 20 FUSE HEATED/ CLIMATE SEAT 21 FUSE HOT W/ EXTENDED IGNITION RELAY ENERGIZED IGN ING PWR LEFT REAR HEAT SEAT FUSE LEFT REAR SEAT BACKREST HEATER LEFT REAR SEAT MODULE LEFT SEAT BACKREST HEATER LIN 1 LIN 4 PASSENGER HEATED SEAT MODULE POWER DISTRIBUTION SYSTEM PPL PPL ING PWR REAR HEAT SEAT SWITCH FUSE REAR JUNCTION BOX REAR SEAT CENTER HEATER SWITCH RIGHT REAR HEAT SEAT FUSE RIGHT REAR HEATED SEAT MODULE RIGHT REAR SEAT BACKREST HEATER RIGHT SEAT BACKREST HEATER SQUAB HTR YEL/ORG WIRE
