Jaguar F-Pace I (2016-2020) yel/ppl Wiring diagrams

This page contains all the electrical diagrams for the component. yel/ppl, in which he is found in the car Jaguar F-Pace I (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram yel/ppl (31 of 49)

Wiring diagram yel/ppl for Jaguar F-Pace I (2016-2020) (31 of 49)

Get access

ACC FUSE ACCELERATOR PEDAL POSITION SENSOR APP GND 1 APP GND 2 APP SIG (1) APP SIG (2) AUTOMATIC SPEED LIMITER (ASL) SWITCH BCM-GWM ASSEMBLY BLK WIRE BLK/YEL WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/WHT WIRE BLU/YEL WIRE BRAKE DIAGNOSTIC SWITCH BRAKE ON/OFF BRAKE PEDAL SWITCH (BRAKE PEDAL BRACKET) BRAKE PEDAL SWITCH FUSE BRN/GRN WIRE BRN/RED WIRE CAN (+) CANCEL (CAN) SWITCH CENTRAL JUNCTION BOX CLOCK- SPRING COMPUTER DATA LINES SYSTEM DEMAND 1 DEMAND 2 DIAG SW ELECTRIC THROTTLE (LEFT SIDE OF ENGINE) EMS PWR FUSIBLE LINK ENGINE CONTROL MODULE (ECM) G R TVA GND 2 GRN WIRE GRN/ORG WIRE GRY WIRE GRY/BLU WIRE GRY/PPL WIRE HOT AT ALL TIMES HOT W/ ENGINE CONTROL MODULE (ECM) RELAY ENERGIZED HOT W/ EXTENDED IGNITION MICRO RELAY ENERGIZED HS CAN H (CO) HS CAN L (CO) HS CAN-H HS CAN-L I BRK I BRK SW I S BRKMN I S BRKRED IGNITION INSTRUMENT CLUSTER LIN LIN 1 O IGN 4 O V SVTVA OT TVMNEG OT TVMPOS POWER GND 1 PPL/BRN WIRE PPL/GRN WIRE PPL/ORG WIRE PPL/RED WIRE REAR ENGINE JUNCTION BOX REAR JUNCTION BOX RESUME (RES) SWITCH RIGHT STEERING WHEEL SWITCHPACK SET SWITCH SPEED CONTROL MODULE STEERING WHEEL MODULE STOPLAMP SWITCH SWM FUSE TRAILER BRAKE CONTROL MODULE V V BAT VBATT VREF 1 VREF 2 WHT WIRE WHT/PPL WIRE YEL WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/PPL WIRE

Go to component -> 2.0l turbo diesel, cruise control circuit -> YEL/PPL WIRE

Wiring diagram yel/ppl (32 of 49)

Wiring diagram yel/ppl for Jaguar F-Pace I (2016-2020) (32 of 49)

Get access

AIR INTAKE + AIR INTAKE FEEDBACK AQS PWM BLU/BRN WIRE BRN WIRE BRN/PPL WIRE BRN/RED WIRE BRN/WHT WIRE CLIMATE CONTROL MODULE DEMIST DISTRIBUTION MOTOR EVAP TEMP EVAPORATOR TEMPERATURE SENSOR GND IN GRN/BLU WIRE GRY WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/RED WIRE GRY/YEL WIRE LEFT FRONT FACE/FEET MOTOR LEFT FRONT TEMPERATURE BLEND MOTOR LIN 1 (HVAC) LIN 1 GND (HVAC) LIN 2 BUS LIN 2 GND LIN 2 PWR LIN 3 LIN 4 LIN IN LIN OUT LIN PWR (HVAC) MTR ORG/ WIRE ORG/GRN WIRE POLLUTION SENSOR PPL/BRN WIRE PPL/GRN WIRE PPL/ORG WIRE PWR PWR IN PWR OUT RECIRCULATED AIR MOTOR RIGHT FRONT FACE AIR DISTRIBUTION MOTOR RIGHT FRONT FEET AIR DISTRIBUTION MOTOR RIGHT FRONT TEMPERATURE BLEND MOTOR RIGHT REAR FACE AIR DISTRIBUTION MOTOR RIGHT REAR FEET AIR DISTRIBUTION MOTOR RIGHT REAR TEMPERATURE BLEND MOTOR SENS GND SENS GND (HVAC) SIG OUTPUT WHT/GRN WIRE YEL/PPL WIRE

Go to component -> Automatic a/c circuit (4 of 6) -> YEL/PPL WIRE

Wiring diagram yel/ppl (33 of 49)

Wiring diagram yel/ppl for Jaguar F-Pace I (2016-2020) (33 of 49)

Get access

BLK WIRE BLK/WHT WIRE BLOCK HEATER BLOCK HEATER HARNESS TO AC MAINS SUPPLY BLOWER RELAY BRN WIRE BRN/BLU WIRE CHARGE AIR COOLANT PUMP EMS PWR FUSIBLE LINK EWP/GTDI OIL FLOW FUSE FRONT BLOWER (RIGHT SIDE DASH) FRONT BLOWER FUSIBLE LINK FRONT BLOWER MOTOR CONTROL MODULE GRN WIRE GRN/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ ENGINE CONTROL MODULE RELAY ENERGIZED ORG/ WIRE PPL/GRN WIRE REAR ENGINE JUNCTION BOX RED WIRE RTN SIG VANAS/ PCV/MAF/ UHEGO FUSE WHT/BLU WIRE YEL/GRN WIRE YEL/PPL WIRE

Go to component -> Automatic a/c circuit (5 of 6) -> YEL/PPL WIRE

Wiring diagram yel/ppl (34 of 49)

Wiring diagram yel/ppl for Jaguar F-Pace I (2016-2020) (34 of 49)

Get access

BATTERY MONITORING SYSTEM MODULE BCM-GWM ASSEMBLY (RIGHT KICK PANEL) BLK WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE CAMERA CONTROL MODULE FRONT ROOF BLIND MOTOR GENERATOR GRN/ORG WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/PPL WIRE GWM CAN H (BO) GWM CAN L (BO) HS CAN H (CH) HS CAN H (CO) HS CAN H (PT) HS CAN L (CH) HS CAN L (CO) HS CAN L (PT) INFOTAINMENT MASTER CONTROLLER (IMC) LEFT "C" PILLAR) LIN LIN 1 BCM LIN 1 GWM LIN 2 BCM LIN 3 MS CAN H (BO) MS CAN L (BO) PPL/GRN WIRE QUIESCENT CURRENT CONTROL MODULE REAR VIEW CAMERA (CENTER OF TAILGATE) ROOF OPENING PANEL MOTOR WHT WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/PPL WIRE

Go to component -> Computer data lines circuit (2 of 7) -> YEL/PPL WIRE

Wiring diagram yel/ppl (35 of 49)

Wiring diagram yel/ppl for Jaguar F-Pace I (2016-2020) (35 of 49)

Get access

17-SPEAKER SYSTEM AUD LIN AUDIO LIN BASE, 11-SPEAKER SYSTEM BLU WIRE BLU/GRN WIRE BLU/WHT WIRE CLOCK- SPRING GRN/ORG WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/PPL WIRE HS CAN H (CH) HS CAN H (CO) HS CAN H (PT) HS CAN L (CH) HS CAN L (CO) HS CAN L (PT) INFOTAINMENT MASTER CONTROLLER (IMC) IPC LIN JAGUAR DRIVE SWITCHPACK LEFT BLIND SPOT MONITORING MODULE LIN LIN 2 NCA WIRE PPL/GRN WIRE REAR CLIMATE CONTROL PANEL RED WIRE RESTRAINTS CONTROL MODULE (RCM) RIGHT BLIND SPOT MONITORING MODULE RIGHT STEERING WHEEL SWITCHPACK STEERING WHEEL MODULE (LEFT SIDE OF STEERING COLUMN) WHT WIRE WHT/RED WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/PPL WIRE

Go to component -> Computer data lines circuit (3 of 7) -> YEL/PPL WIRE

Wiring diagram yel/ppl (36 of 49)

Wiring diagram yel/ppl for Jaguar F-Pace I (2016-2020) (36 of 49)

Get access

BLK WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BRN/PPL WIRE CLIMATE CONTROL MODULE CONTINUOUSLY VARIABLE DAMPING MODULE GRN WIRE GRN/ORG WIRE GRY/BLU WIRE GRY/PPL WIRE HEAD-UP DISPLAY CONTROL MODULE HEAD-UP DISPLAY COOLING FAN MODULE HS CAN H (CH) HS CAN H (CO) HS CAN H (PT) HS CAN L (CH) HS CAN L (CO) HS CAN L (PT) INSTRUMENT CLUSTER INTEGRATED CLIMATE CONTROL MODULE, SWITCHPACK LEFT "C" PILLAR) LIN LIN (HVAC) LIN 4 MS CAN H (BO) MS CAN L (BO) OCCUPANT CLASSIFICATION SENSOR CONTROL MODULE PPL/GRN WIRE SPEED CONTROL MODULE TELEMATIC CONTROL MODULE TIRE PRESSURE MONITORING SYSTEM MODULE YEL/ORG WIRE YEL/PPL WIRE

Go to component -> Computer data lines circuit (4 of 7) -> YEL/PPL WIRE

Wiring diagram yel/ppl (37 of 49)

Wiring diagram yel/ppl for Jaguar F-Pace I (2016-2020) (37 of 49)

Get access

2.0L TURBO DIESEL 2.0L TURBO DIESEL 3.0L SC ABS CONTROL MODULE BLU WIRE BLU/GRN WIRE BRN/PPL WIRE CENTER REAR HEATER SWITCH DRIVER HEATED SEAT MODULE GRN WIRE GRN/ORG WIRE GRY/BLU WIRE HS CAN H (CH) HS CAN H (PT) HS CAN L (CH) HS CAN L (PT) LEFT FRONT CLIMATE CONTROL SEAT MODULE LEFT REAR SEAT MODULE LIN 1 LIN 4 PASSENGER HEATED SEAT MODULE POWER STEERING CONTROL MODULE RIGHT FRONT CLIMATE CONTROL SEAT MODULE RIGHT REAR SEAT MODULE TRANSFER CASE CONTROL MODULE W/ CLIMATE CONTROL SEAT W/O CLIMATE CONTROL SEAT YEL/ORG WIRE YEL/PPL WIRE

Go to component -> Computer data lines circuit (5 of 7) -> YEL/PPL WIRE

Wiring diagram yel/ppl (38 of 49)

Wiring diagram yel/ppl for Jaguar F-Pace I (2016-2020) (38 of 49)

Get access

BLK WIRE DEPLOYABLE TOWBAR CONTROL MODULE KEYLESS VEHICLE MODULE MS CAN H (BO) MS CAN L (BO) RIGHT FRONT DOOR MODULE RIGHT FRONT SEAT MODULE RIGHT REAR DOOR MODULE UPPER TAILGATE CONTROL MODULE YEL/ORG WIRE YEL/PPL WIRE

Go to component -> Computer data lines circuit (7 of 7) -> YEL/PPL WIRE

Wiring diagram yel/ppl (39 of 49)

Wiring diagram yel/ppl for Jaguar F-Pace I (2016-2020) (39 of 49)

Get access

BATTERY JUNCTION BOX BCM-GWM ASSEMBLY BLK WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BRN/BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM CONTINUOUSLY VARIABLE DAMPING MODULE ECU GND 1 FUSIBLE LINK 5 GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/WHT WIRE GRY/BLU WIRE HOT AT ALL TIMES HS CAN H (CH) HS CAN H (PT) HS CAN L (CH) LF VA SIG HS CAN L (PT) IGN 2 IN IGN 8 LEFT FRONT ACCELEROMETER LEFT REAR DAMPER SOLENOID LEFT REAR HEIGHT SENSOR LF VA GND LR DAMPER NEG LR DAMPER POS LR HEIGHT GND LR HEIGHT SIG PPL PPL/GRY WIRE PPL/ORG WIRE PWR REAR ACCELEROMETER RIGHT REAR HEIGHT SENSOR RR DAMPER NEG RR DAMPER POS RR HEIGHT GND RR HEIGHT SIG RR VA GND RR VA SIG SIG VBATT 2 WHT/PPL WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/PPL WIRE

Go to component -> Electronic suspension circuit (2 of 2) -> YEL/PPL WIRE

Wiring diagram yel/ppl (40 of 49)

Wiring diagram yel/ppl for Jaguar F-Pace I (2016-2020) (40 of 49)

Get access

BCM-GWM ASSEMBLY BLK WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE CENTRAL JUNCTION BOX CLOCK- SPRING FRONT ENGINE JUNCTION BOX GND IN GRY WIRE HORN CONTROL HORN IN HORN RELAY HORN SWITCH HORNS FUSE HOT AT ALL TIMES LEFT HORN (BEHIND GRILLE) LEFT STEERING WHEEL SWITCHPACK LIN LIN 1 LOGIC GND NCA WIRE PPL/GRN WIRE PPL/RED WIRE RED WIRE RIGHT HORN (BEHIND GRILLE) RIGHT STEERING WHEEL SWITCHPACK STEERING WHEEL MODULE SWM FUSE V BATT WHT WIRE YEL/PPL WIRE YEL/RED WIRE

Go to component -> Horn circuit -> YEL/PPL WIRE
