Jaguar F-Pace I (2016-2020) w/ auto dimming rear view mirror, rain sensor Wiring diagram
This page shows the only wiring diagram for the component.w/ auto dimming rear view mirror, rain sensor, which is found in the car Jaguar F-Pace I (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ auto dimming rear view mirror, rain sensor (1 of 1)
10-WAY
2.0L TURBO DIESEL
8 WAY
AUDIO HEAD UNIT
AUXILIARY BLOWER CONTROL MODULE
BLK WIRE
BLK/GRN WIRE
CENTRAL JUNCTION BOX
DOWN STREAM SCR NOX SENSOR
FRONT OVERHEAD CONSOLE
LEFT FRONT DOOR SILL LAMP
LEFT FRONT SEAT MODULE
LEFT LUMBAR PUMP
LEFT LUMBAR PUMP SOLENOID
LEFT LUMBER PUMP
LEFT PUMP LUMBAR SOLENOID
LEFT REAR INTERIOR LAMP
LEFT REAR RECLINE BACKREST SEAT MOTOR
LEFT REAR SEATS SWITCHPACK
LEFT SEAT SWITCHPACK
LEFT VANITY MIRROR
LEFT WIND SHIELD HEATER
PARKING AID CONTROL MODULE
PASSENGER HEATED SEAT MODULE
RAIN/ LIGHT SENSOR
REAR VIEW MIRROR)
RED WIRE
RF RECEIVER
RIGHT BACKREST SEAT HEATER
RIGHT FRONT CLIMATE CONTROL SEAT MODULE
RIGHT FRONT DOOR SILL LAMP
RIGHT FRONT SEAT MODULE
RIGHT LUMBAR PUMP
RIGHT LUMBAR PUMP SOLENOID
RIGHT PUMP LUMBAR SOLENOID
RIGHT REAR AIMREST AMBIENCE LIGHTING
RIGHT REAR DOOR HANDLE AMBIENCE LIGHTING LED
RIGHT REAR DOOR MODULE
RIGHT REAR DOOR POCKET AMBIENCE LIGHTING LED
RIGHT REAR FOOTWELL LAMP
RIGHT REAR INTERIOR LAMP
RIGHT VANITY MIRROR
RIGHT WINDSHIELD HEATER
TEMPERATURE/ HUMIDITY SENSOR
W/ AUTO DIMMING REAR VIEW MIRROR, RAIN SENSOR
W/ HEATED SEATS
W/O MEMORY
Go to component: -> Ground distribution circuit (3 of 6) -> W/ AUTO DIMMING REAR VIEW MIRROR, RAIN SENSOR
