Jaguar F-Pace I (2016-2020) vane vgt actuator Wiring diagram
This page shows the only wiring diagram for the component.vane vgt actuator, which is found in the car Jaguar F-Pace I (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vane vgt actuator (1 of 1)
ACTIVE ENGINE MOUNT SOLENOID
ACTIVE GRILLE AIR SHUTTER MOTOR
ALE
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRAKE DIAGNOSTIC SWITCH
BRAKE PEDAL SWITCH (BRAKE PEDAL BRACKET)
BRAKE PEDAL SWITCH FUSE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
CENTRAL JUNCTION BOX
EGR COOLER BYPASS SOLENOID VALVE
FRONT OF RADIATOR)
FUEL PRESSURE CONTROL VALVE
FUEL VOLUME CONTROL VALVE
GRN WIRE
GRN/BRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/ORG WIRE
GRY/PPL WIRE
HIGH PRESSURE EGR COOLER OUTLET TEMPERATURE SENSOR
HOT AT ALL TIMES
HTR
HTR+ IPE
LIN
LOW PRESSURE EGR SOLENOID VALVE
OIL PRESSURE/ TEMPERATURE SENSOR
ORG/ WIRE
ORG/BLU WIRE
ORG/GRN WIRE
PPL
PPL/BRN WIRE
PPL/GRN WIRE
PPL/ORG WIRE
PWR
RED WIRE
SIGNAL
STOP LAMP SWITCH
SUPPLY
TURBOCHARGER BYPASS COMPRESSOR SOLENOID
VANE VGT ACTUATOR
WHT WIRE
YEL WIRE
YEL/PPL WIRE
Go to component: -> Wiring diagram engine performance 2.0l turbo diesel (5 of 8) -> VANE VGT ACTUATOR
