Jaguar F-Pace I (2016-2020) sunroof close sw wiring diagram
This page shows the only wiring diagram for the component.sunroof close sw, which is found in the car Jaguar F-Pace I (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
sunroof close sw wiring diagram (1 of 1)
BCM-GWM ASSEMBLY
BLK WIRE
BLU/WHT WIRE
BRN/GRN WIRE
CENTRAL JUNCTION BOX
CONFIG SBM
CONFIG SINGLE MOTOR
FR SW BLIND CLOSE
FR SW BLIND OPEN
FRONT OVERHEAD CONSOLE
FRONT ROOF BLIND MOTOR (REAR OF HEADLINER)
GRN/WHT WIRE
GRY/BRN WIRE
GRY/PPL WIRE
HALL A OUTPUT
HOT AT ALL TIMES
LIGHTING 1
LIN
LIN 3
O DEMAND INTERIOR
PPL/BRN WIRE
ROOF BLIND CLOSE
ROOF BLIND OPEN
ROOF OPENING PANEL MOTOR (REAR OF HEADLINER)
SUNROOF CLOSE SW
SUNROOF FUSE
SUNROOF OPEN SUNROOF CLOSE
SUNROOF OPEN SW
VBATT
WHT/RED WIRE
YEL/ORG WIRE
Go to component -> Power top/sunroof circuit -> SUNROOF CLOSE SW
