Jaguar F-Pace I (2016-2020) right pre catalyst heated oxygen sensor Wiring diagram
This page shows the only wiring diagram for the component.right pre catalyst heated oxygen sensor, which is found in the car Jaguar F-Pace I (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right pre catalyst heated oxygen sensor (1 of 1)
AMBIENT AIR TEMPERATURE SENSOR
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/PPL WIRE
BRN/WHT WIRE
BRN/YEL WIRE
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/PPL WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
GRY/PPL WIRE
GRY/YEL WIRE
INTAKE CAMSHAFT POSITION SENSOR (BANK 1)
INTAKE CAMSHAFT POSITION SENSOR (BANK 2)
LEFT DOOR MIRROR
OUTLET CAMSHAFT POSITION SENSOR (BANK 1)
OUTLET CAMSHAFT POSITION SENSOR (BANK 2)
PPL
PPL/GRN WIRE
PPL/GRY WIRE
PPL/ORG WIRE
RED WIRE
RIGHT MID CATALYST HEATED OXYGEN SENSOR
RIGHT POST CATALYST HEATED OXYGEN SENSOR
RIGHT PRE CATALYST HEATED OXYGEN SENSOR
SENS
SIG
VREF
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/PPL WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 3.0l sc (3 of 9) -> RIGHT PRE CATALYST HEATED OXYGEN SENSOR
