Jaguar F-Pace I (2016-2020) ppl ing pwr Wiring diagram
This page shows the only wiring diagram for the component.ppl ing pwr, which is found in the car Jaguar F-Pace I (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl ing pwr (1 of 1)
BLK WIRE
BLU/BRN WIRE
BRN WIRE
BRN/PPL WIRE
CENTRAL JUNCTION BOX
COMPUTER DATA LINES SYSTEM
DRIVER HEATED SEAT MODULE
GRN WIRE
GRN/PPL WIRE
GRY WIRE
GRY/ORG WIRE
GRY/PPL WIRE
HEATED/ CLIMATE SEAT 20 FUSE
HEATED/ CLIMATE SEAT 21 FUSE
HOT W/ EXTENDED IGNITION RELAY ENERGIZED
IGN
ING PWR
LEFT REAR HEAT SEAT FUSE
LEFT REAR SEAT BACKREST HEATER
LEFT REAR SEAT MODULE
LEFT SEAT BACKREST HEATER
LIN 1
LIN 4
PASSENGER HEATED SEAT MODULE
POWER DISTRIBUTION SYSTEM
PPL
PPL ING PWR
REAR HEAT SEAT SWITCH FUSE
REAR JUNCTION BOX
REAR SEAT CENTER HEATER SWITCH
RIGHT REAR HEAT SEAT FUSE
RIGHT REAR HEATED SEAT MODULE
RIGHT REAR SEAT BACKREST HEATER
RIGHT SEAT BACKREST HEATER
SQUAB HTR
YEL/ORG WIRE
Go to component: -> Heated seats circuit -> PPL ING PWR
