Jaguar F-Pace I (2016-2020) o demand interior Wiring diagram

This page shows the only wiring diagram for the component.o demand interior, which is found in the car Jaguar F-Pace I (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram o demand interior (1 of 1)

Wiring diagram o demand interior for Jaguar F-Pace I (2016-2020)

Get access

BCM-GWM ASSEMBLY BLK WIRE BLU/WHT WIRE BRN/GRN WIRE CENTRAL JUNCTION BOX CONFIG SBM CONFIG SINGLE MOTOR FR SW BLIND CLOSE FR SW BLIND OPEN FRONT OVERHEAD CONSOLE FRONT ROOF BLIND MOTOR (REAR OF HEADLINER) GRN/WHT WIRE GRY/BRN WIRE GRY/PPL WIRE HALL A OUTPUT HOT AT ALL TIMES LIGHTING 1 LIN LIN 3 O DEMAND INTERIOR PPL/BRN WIRE ROOF BLIND CLOSE ROOF BLIND OPEN ROOF OPENING PANEL MOTOR (REAR OF HEADLINER) SUNROOF CLOSE SW SUNROOF FUSE SUNROOF OPEN SUNROOF CLOSE SUNROOF OPEN SW VBATT WHT/RED WIRE YEL/ORG WIRE

Go to component: -> Power top/sunroof circuit -> O DEMAND INTERIOR
