Jaguar F-Pace I (2016-2020) left rear seat backrest recline motor Wiring diagram

This page shows the only wiring diagram for the component.left rear seat backrest recline motor, which is found in the car Jaguar F-Pace I (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left rear seat backrest recline motor (1 of 1)

Wiring diagram left rear seat backrest recline motor for Jaguar F-Pace I (2016-2020)

Get access

BLK WIRE CENTRAL JUNCTION BOX GRY/PPL WIRE HOT AT ALL TIMES INCLINE LEFT REAR SEAT BACKREST RECLINE MOTOR LEFT REAR SEATS SWITCHPACK MOTOR + UP MOTOR DOWN NCA WIRE POWER PPL/RED WIRE RECLINE RED WIRE RIGHT REAR SEAT BACKREST RECLINE MOTOR RIGHT REAR SEATS SWITCHPACK YEL/PPL WIRE

Go to component: -> Rear power seat circuit -> LEFT REAR SEAT BACKREST RECLINE MOTOR
