Jaguar F-Pace I (2016-2020) jaguar drive switchpack Wiring diagrams

This page contains all the electrical diagrams for the component. jaguar drive switchpack, in which he is found in the car Jaguar F-Pace I (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram jaguar drive switchpack (1 of 3)

Wiring diagram jaguar drive switchpack for Jaguar F-Pace I (2016-2020)

Get access

17-SPEAKER SYSTEM AUD LIN AUDIO LIN BASE, 11-SPEAKER SYSTEM BLU WIRE BLU/GRN WIRE BLU/WHT WIRE CLOCK- SPRING GRN/ORG WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/PPL WIRE HS CAN H (CH) HS CAN H (CO) HS CAN H (PT) HS CAN L (CH) HS CAN L (CO) HS CAN L (PT) INFOTAINMENT MASTER CONTROLLER (IMC) IPC LIN JAGUAR DRIVE SWITCHPACK LEFT BLIND SPOT MONITORING MODULE LIN LIN 2 NCA WIRE PPL/GRN WIRE REAR CLIMATE CONTROL PANEL RED WIRE RESTRAINTS CONTROL MODULE (RCM) RIGHT BLIND SPOT MONITORING MODULE RIGHT STEERING WHEEL SWITCHPACK STEERING WHEEL MODULE (LEFT SIDE OF STEERING COLUMN) WHT WIRE WHT/RED WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/PPL WIRE

Go to component: -> Computer data lines circuit (3 of 7) -> JAGUAR DRIVE SWITCHPACK

Wiring diagram jaguar drive switchpack (2 of 3)

Wiring diagram jaguar drive switchpack for Jaguar F-Pace I (2016-2020)

Get access

ALL SURFACE PROGRESS CONTROL SWITCH AUDIO-VIDEO INPUT/OUTPUT PANEL BLK WIRE BLK/GRN WIRE BLK/PPL WIRE BLK/WHT WIRE BLU WIRE CENTER CONSOLE ILLUMINATION CLIMATE CONTROL MODULE CLOCK- SPRING DIAGNOSTIC CONNECTOR ELECTRIC PARK BRAKE SWITCH FUEL FIRED BOOSTER HEATER GLOVE BOX SWITCH HEAD-UP DISPLAY CONTROL MODULE HEAD-UP DISPLAY COOLING FAN HEAD-UP DISPLAY COOLING FAN MODULE IMMOBILIZER ANTENNA UNIT INSTRUMENT CLUSTER INTEGRATED CLIMATE CONTROL MODULE, SWITCHPACK JAGUAR DRIVE SWITCHPACK LEFT CONSOLE ILLUMINATION LEFT FRONT FOOTWELL LAMP LEFT FRONT OUTER VENT ILLUMINATION LEFT HORN NCA WIRE PASSENGER SIDE INSTRUMENT PANEL ILLUMINATION PORTABLE AUDIO INTER FACE MODULE RIGHT CONSOLE ILLUMINATION RIGHT FRONT FOOTWELL LAMP RIGHT FRONT OUTER VENT ILLUMINATION RIGHT HORN STEERING WHEEL HEATER STEERING WHEEL MODULE TOUCH SCREEN SWITCHPACK TRANSMISSION CONTROL SWITCH W/ IN CONTROL APPS W/ NLI HEAD UNIT LEVEL B W/O IN CONTROL APPS

Go to component: -> Ground distribution circuit (2 of 6) -> JAGUAR DRIVE SWITCHPACK

Wiring diagram jaguar drive switchpack (3 of 3)

Wiring diagram jaguar drive switchpack for Jaguar F-Pace I (2016-2020)

Get access

ABS CONTROL MODULE ALL SURFACE PROGRESS CONTROL SWITCH BATTERY JUNCTION BOX BCM-GWM ASSEMBLY BLK WIRE BLK/WHT WIRE BLU WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSIBLE LINK 6 GRN/BRN WIRE GRN/ORG WIRE GRY/BLU WIRE HDC HI HDC LO HOT AT ALL TIMES HS CAN H (CH) HS CAN H (PT) HS CAN L (CH) HS CAN L (CH) GND HS CAN L (PT) IGN IGN 5 ILLUM INSTRUMENT CLUSTER JAGUAR DRIVE SWITCHPACK ORG/BLU WIRE VBATT 1

Go to component: -> Terrain response circuit -> JAGUAR DRIVE SWITCHPACK
