Jaguar F-Pace I (2016-2020) i brake pad wear Wiring diagram
This page shows the only wiring diagram for the component.i brake pad wear, which is found in the car Jaguar F-Pace I (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram i brake pad wear (1 of 1)
ACCESSORY SOCKET 1 CONTROL
ACCESSORY SOCKET 2 CONTROL
ANTI-THEFT SYSTEM
BATTERY JUNCTION BOX
BCM-GWM ASSEMBLY (RIGHT KICK PANEL)
BLK WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CHMSL
DEFOGGER SYSTEM
DRIVER AJAR SW
ELECTRONIC SUSPENSION SYSTEM
ENGINE CONTROLS SYSTEM
ENGINE RUNNING CONTROL
FRONT PASSENGER SBR SWITCH
FUEL FLAP UNLOCK
FUEL SENS EJECT
FUEL SENS PUMP
FUSIBLE LINK 5
FUSIBLE LINK 6
GND FUEL RETURN
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY WIRE
GRY/ORG WIRE
GRY/PPL WIRE
HEATED REAR SCREEN CONTROL
HOT AT ALL TIMES
I BRAKE PAD WEAR
I EVENT NOTIFICATION SIG
INTERIOR LIGHT SWITCH
LEFT REAR O DIRECTION INDICATOR
LEFT REAR POSITION LIGHT
LR AJAR SW
O COMFORT SPLY CTRL
O EXT IGN CTRL 2
O FUEL FLAP LOCK
O FUEL PUMP CONTROL
O IGNITION 1
O IGNITION 5
O IGNITION 8
O NUMBER PLATE LAMPS
O RESTRAINTS IGNITION 1
PASSENGER AJAR SW
POWER DISTRIBUTION SYSTEM
PPL/GRN WIRE
PPL/GRY WIRE
REAR WIPER CONTROL
REAR WIPER PARK SWITCH
RIGHT REAR O POSITION LIGHT
RR AJAR SW
SUPPLEMENTAL RESTRAINTS SYSTEM
TAILGATE AJAR SWITCH
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VBATT 1
VBATT 2
WARNING SYSTEMS
WHT WIRE
WHT/BRN WIRE
WIPER/WASHER SYSTEM
YEL WIRE
YEL/GRY WIRE
YEL/PPL WIRE
Go to component -> Body control modules circuit (1 of 3) -> I BRAKE PAD WEAR
