Jaguar F-Pace I (2016-2020) horns fuse Wiring diagrams

BCM-GWM ASSEMBLY BLK WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE CENTRAL JUNCTION BOX CLOCK- SPRING FRONT ENGINE JUNCTION BOX GND IN GRY WIRE HORN CONTROL HORN IN HORN RELAY HORN SWITCH HORNS FUSE HOT AT ALL TIMES LEFT HORN (BEHIND GRILLE) LEFT STEERING WHEEL SWITCHPACK LIN LIN 1 LOGIC GND NCA WIRE PPL/GRN WIRE PPL/RED WIRE RED WIRE RIGHT HORN (BEHIND GRILLE) RIGHT STEERING WHEEL SWITCHPACK STEERING WHEEL MODULE SWM FUSE V BATT WHT WIRE YEL/PPL WIRE YEL/RED WIRE

BCM-GWM ASSEMBLY BLK WIRE BLU/ORG WIRE BRN WIRE CENTRAL JUNCTION BOX CLIMATE CONTROL MODULE DRIVER HEATED SEAT MODULE EXTENDED IGNITION RELAY FROM BATTERY JUNCTION BOX (DIAGRAM 1 OF 8) FRONT CONSOLE OVERHEAD FRONT ENGINE JUNCTION BOX FUEL FIRED BOOSTER HEATER (FFBH) RECEIVER GRN WIRE GRN/YEL WIRE GRY/ORG WIRE GRY/PPL WIRE GRY/RED WIRE HEATED STEERING WHEEL FUSE HEATED/ CLIMATE SEAT 20 FUSE HEATED/ CLIMATE SEAT 21 FUSE HEVAC CLUTCH FUSE HORN RELAY HORNS FUSE KEYLESS VEHICLE MODULE KVM LATCH FUSE KVM LOGIC FUSE LEFT FRONT CLIMATE CONTROL MODULE LEFT REAR DOOR MODULE LHR DOOR MODULE FUSE N/A PASSENGER FRONT HEATED SEAT MODULE PPL/GRN WIRE PPL/RED WIRE RED WIRE RF RECEIVER RFR FUSE RHF DOOR MODULE FUSE RIGHT FRONT CLIMATE CONTROL MODULE RIGHT FRONT DOOR MODULE ROAD PRICING CONNECTOR ROAD PRICING FUSE SPARE FUSE STEERING WHEEL MODULE SWM FUSE TIRE PRESSURE MONITORING SYSTEM MODULE TO FRONT ENGINE JUNCTION BOX (DIAGRAM 1 OF 8) VICS FUSE W/ FUEL OPERATOR HEATER WHT/BRN WIRE WHT/RED WIRE YEL/ORG WIRE YEL/RED WIRE
