Jaguar F-Pace I (2016-2020) gnd stop Wiring diagram
This page shows the only wiring diagram for the component.gnd stop, which is found in the car Jaguar F-Pace I (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gnd stop (1 of 1)
ACC FUSE
ACTIVE CAMERA FUSE
BCM-GWM ASSEMBLY
BLK WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BRN WIRE
BRN/PPL WIRE
CONTROL/ DIAGNOSTICS
CRANK
DC-DC CONVERTER MODULE
FROM BATTERY JUNCTION BOX (DIAGRAM 1 OF 8)
FROM BATTERY MONITORING SYSTEM
FROM CENTRAL JUNCTION BOX (DIAGRAM 5 OF 8)
FROM REAR JUNCTION BOX (DIAGRAM 6 OF 8)
FUSE 7
GND STOP
GRN/WHT WIRE
GRY/PPL WIRE
GRY/YEL WIRE
GWM LIN 2
HEAD-UP DISPLAY CONTROL MODULE
HEAD-UP DISPLAY COOLING FAN
HEAD-UP DISPLAY COOLING FAN MODULE
HUD FUSE
I START STOP
IGN
IGN 1
IMAGE PROCESSING CONTROL MODULE
IMAGE PROCESSING MODULE
INTEGRATED CLIMATE CONTROL MODULE, SWITCHPACK
LEFT BLIND SPOT MONITORING MODULE
LIN 2
MIRROR ELEC/ BSM/ CAM FUSE
MODULE (DIAGRAM 1 OF 8)
RAIN/LIGHT SENSOR
REAR JUNCTION BOX
REAR VIEW CAMERA
REAR VIEW MIRROR)
RED WIRE
RIGHT BLIND SPOT MONITORING MODULE
SOCKET 2 CTRL
SPEED CONTROL MODULE
START STOP SW GND
START/ STOP SW 1
START/ STOP SW 2
STARTING/ CHARGING SYSTEM
TO REAR JUNCTION BOX (DIAGRAM 6 OF 8)
VOLTAGE QUALITY MODULE
W/ STOP/START SYSTEM
WHT WIRE
WHT/BRN WIRE
WHT/RED WIRE
YEL/ORG WIRE
YEL/PPL WIRE
Go to component: -> Power distribution circuit (8 of 8) -> GND STOP
