Jaguar F-Pace I (2016-2020) glow plug control module Wiring diagrams
This page contains all the electrical diagrams for the component. glow plug control module, in which he is found in the car Jaguar F-Pace I (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram glow plug control module (1 of 2)
2.0L TURBO DIESEL
ABS CONTROL MODULE
ACTIVE GRILLE AIR SHUTTER MOTOR
AUXILIARY LIGHTING SWITCH
BATTERY BACKUP SOUNDER
BCM-GWM ASSEMBLY
BLK WIRE
BLK/YEL WIRE
BLOCK HEATER HARNESS AC MAINS SUPPLY
BOT CLUTCH SWITCH
BRAKE FLUID LEVEL SENSOR
BRAKE PEDAL SWITCH
BRAKE VACUUM SWITCH
CAPACITOR
CHANGEOVER VALVE
CHARGE AIR COOLANT PUMP
FRONT ENGINE JUNCTION BOX
GLOW PLUG CONTROL MODULE
GRN WIRE
HEATER BLOCK
HOOD SWITCH
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
LEFT FRONT BRAKE PAD WEAR SENSOR
LEFT FRONT FOG LAMP
LEFT HEADLAMP
LEFT HEATED WASHER JET
LOW COOLANT SWITCH
MAIN ELECTRIC COOLING FAN
PASSIVE SOUNDER
POWER STEERING CONTROL MODULE
POWER WASH PUMP
REAR ENGINE JUNCTION BOX
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
RIGHT HEATED WASHER JET
SPEED CONTROL MODULE
TRANSFER CASE CONTROL MODULE
TRANSMISSION CONTROL MODULE
UPSTREAM SCR NOX SENSOR
W/ PASSIVE
W/O PASSIVE
WASHER FLUID LEVEL SENSOR
WATER IN-FUEL SENSOR
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit (1 of 6) -> GLOW PLUG CONTROL MODULE
Wiring diagram glow plug control module (2 of 2)
2.0L TURBO DIESEL
ABS CONTROL MODULE
ABS PUMP FUSIBLE LINK
BATTERY
BATTERY JUNCTION BOX
BATTERY MONITORING SYSTEM MODULE
BCM-GWM ASSEMBLY
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
CABLE JUNCTION STUD
CHARGE AIR COOLANT PUMP RELAY
COOLANT PUMP SC FUSE
COOLING FAN MOTOR FUSIBLE LINK
EXTENDED IGNITION RELAY
FROM CENTRAL JUNCTION BOX (DIAGRAM 2 OF 8)
FUSIBLE LINK 1
FUSIBLE LINK 10
FUSIBLE LINK 11
FUSIBLE LINK 12
FUSIBLE LINK 3
FUSIBLE LINK 4
FUSIBLE LINK 5
FUSIBLE LINK 6
FUSIBLE LINK 7
FUSIBLE LINK 8
FUSIBLE LINK 9
GCU FUSIBLE LINK
GENERATOR
GLOW PLUG CONTROL MODULE
GRN WIRE
GRY WIRE
MAIN ELECTRIC COOLING FAN
NCA WIRE
PPL
RED WIRE
STARTER MOTOR
THROUGH PANEL STUD
TO CENTRAL JUNCTION BOX (DIAGRAM 2 OF 8)
TO CENTRAL JUNCTION BOX (DIAGRAM 5 OF 8)
TO EPAS FUSIBLE LINK (DIAGRAM 4 OF 8)
TO FRONT ENGINE JUNCTION BOX (DIAGRAM 4 OF 8)
TO QUIESCENT CURRENT CONTROL MODULE (DIAGRAM 3 OF 8)
TO REAR ENGINE JUNCTION BOX (DIAGRAM 4 OF 8)
TO REAR JUNCTION BOX (DIAGRAM 6 OF 8)
TO REAR JUNCTION BOX (DIAGRAM 8 OF 8)
TO VOLTAGE QUALITY MODULE (DIAGRAM 8 OF 8)
UNDER BONNET FUSE BOX
WHT WIRE
WHT/BRN WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (1 of 8) -> GLOW PLUG CONTROL MODULE
