Jaguar F-Pace I (2016-2020) fusible link 11 Wiring diagram

2.0L TURBO DIESEL ABS CONTROL MODULE ABS PUMP FUSIBLE LINK BATTERY BATTERY JUNCTION BOX BATTERY MONITORING SYSTEM MODULE BCM-GWM ASSEMBLY BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE CABLE JUNCTION STUD CHARGE AIR COOLANT PUMP RELAY COOLANT PUMP SC FUSE COOLING FAN MOTOR FUSIBLE LINK EXTENDED IGNITION RELAY FROM CENTRAL JUNCTION BOX (DIAGRAM 2 OF 8) FUSIBLE LINK 1 FUSIBLE LINK 10 FUSIBLE LINK 11 FUSIBLE LINK 12 FUSIBLE LINK 3 FUSIBLE LINK 4 FUSIBLE LINK 5 FUSIBLE LINK 6 FUSIBLE LINK 7 FUSIBLE LINK 8 FUSIBLE LINK 9 GCU FUSIBLE LINK GENERATOR GLOW PLUG CONTROL MODULE GRN WIRE GRY WIRE MAIN ELECTRIC COOLING FAN NCA WIRE PPL RED WIRE STARTER MOTOR THROUGH PANEL STUD TO CENTRAL JUNCTION BOX (DIAGRAM 2 OF 8) TO CENTRAL JUNCTION BOX (DIAGRAM 5 OF 8) TO EPAS FUSIBLE LINK (DIAGRAM 4 OF 8) TO FRONT ENGINE JUNCTION BOX (DIAGRAM 4 OF 8) TO QUIESCENT CURRENT CONTROL MODULE (DIAGRAM 3 OF 8) TO REAR ENGINE JUNCTION BOX (DIAGRAM 4 OF 8) TO REAR JUNCTION BOX (DIAGRAM 6 OF 8) TO REAR JUNCTION BOX (DIAGRAM 8 OF 8) TO VOLTAGE QUALITY MODULE (DIAGRAM 8 OF 8) UNDER BONNET FUSE BOX WHT WIRE WHT/BRN WIRE YEL WIRE YEL/RED WIRE
