Jaguar F-Pace I (2016-2020) changeover valve Wiring diagrams
This page contains all the electrical diagrams for the component. changeover valve, in which he is found in the car Jaguar F-Pace I (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
changeover valve wiring diagram (1 of 3)
A/C CLUTCH RLY CTRL
BATTERY JUNCTION BOX
BCM-GWM ASSEMBLY (RIGHT KICK PANEL)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BLWR MTR RLY CTRL
BRN WIRE
BRN/GRN WIRE
BRN/PPL WIRE
CHANGEOVER VALVE
CLIMATE CONTROL MODULE (RIGHT SIDE DASH)
CLUTCH PWR IN
COMP SOL + PPL COMP SOL -
COMPUTER DATA LINES SYSTEM
FB HTR DIV VLV
FL FACE DUCT SENS
FR FACE DUCT SENS
FR FOOT DUCT SENS
FRONT ENGINE JUNCTION BOX
FUSE 15
FUSIBLE LINK 6
GRN WIRE
GRN/BLU WIRE
GRN/PPL WIRE
GRY WIRE
GRY/BRN WIRE
GRY/PPL WIRE
GRY/YEL WIRE
GWM HS CAN H (CH)
GWM HS CAN L (CH)
HOT AT ALL TIMES
HOT W/ MICRO RELAY 2 ENERGIZED
HS CAN-H
HS CAN-L
IN CAR TEMP SENS
LH SOLAR SENS
LIN 1
LIN 1 (HVAC) FL FOOT DUCT SENS
LIN 4
MTR GND
MTR PWR
O IGNITION 5
PPL
PPL/GRN WIRE
PPL/GRY WIRE
PPL/ORG WIRE
PPL/RED WIRE
PPL/WHT WIRE
PRESS SENS
PTC HTR 2 RLY CTRL
PTC HTR RLY 1 CTRL
PWR
QUIESCENT CURRENT CONTROL MODULE
REAR BLOWER FUSIBLE LINK
REAR BLOWER RELAY
REAR BLWR RLY CTRL
REAR CLIMATE CONTROL PANEL
RH SOLAR SENS
RL FACE DUCT SENS
RL FOOT DUCT SENS
RR FACE DUCT SENS
RR FOOT DUCT SENS
SENS GND (VEH)
TEMPERATURE/ HUMIDITY SENSOR
VBATT
VBATT 1
W/ FRONT/REAR AIR CONDITIONING
WHT/BRN WIRE
WHT/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component -> Automatic a/c circuit (1 of 6) -> CHANGEOVER VALVE
changeover valve wiring diagram (2 of 3)
BLK WIRE
BRN WIRE
BRN/BLU WIRE
BRN/PPL WIRE
CENTRAL JUNCTION BOX
CHANGEOVER VALVE
CLIMATE CONTROL MODULE
DIV VLV
F PMP +
FB HTR
FUEL FIRED BOOSTER HEATER
FUEL FIRED BOOSTER HEATER (FFBH) COOLANT PUMP
FUEL FIRED BOOSTER HEATER (FFBH) PUMP
FUEL FIRED BOOSTER HEATER (FFBH) RECEIVER
FUEL FIRED BOOSTER HEATER ANTENNA
FUSE 16
FUSE 17
GRN WIRE
GRN/ORG WIRE
GRN/PPL WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ GRAPHICAL RELAY 2 ENERGIZED
LIN
LIN 4
NCA WIRE
QUIESCENT CURRENT CONTROL MODULE
REC SIG
RED WIRE
RF SIG
SCR
V BATT
WHT/VIO WIRE
Go to component -> Fuel fired heater circuit -> CHANGEOVER VALVE
changeover valve wiring diagram (3 of 3)
2.0L TURBO DIESEL
ABS CONTROL MODULE
ACTIVE GRILLE AIR SHUTTER MOTOR
AUXILIARY LIGHTING SWITCH
BATTERY BACKUP SOUNDER
BCM-GWM ASSEMBLY
BLK WIRE
BLK/YEL WIRE
BLOCK HEATER HARNESS AC MAINS SUPPLY
BOT CLUTCH SWITCH
BRAKE FLUID LEVEL SENSOR
BRAKE PEDAL SWITCH
BRAKE VACUUM SWITCH
CAPACITOR
CHANGEOVER VALVE
CHARGE AIR COOLANT PUMP
FRONT ENGINE JUNCTION BOX
GLOW PLUG CONTROL MODULE
GRN WIRE
HEATER BLOCK
HOOD SWITCH
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
LEFT FRONT BRAKE PAD WEAR SENSOR
LEFT FRONT FOG LAMP
LEFT HEADLAMP
LEFT HEATED WASHER JET
LOW COOLANT SWITCH
MAIN ELECTRIC COOLING FAN
PASSIVE SOUNDER
POWER STEERING CONTROL MODULE
POWER WASH PUMP
REAR ENGINE JUNCTION BOX
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
RIGHT HEATED WASHER JET
SPEED CONTROL MODULE
TRANSFER CASE CONTROL MODULE
TRANSMISSION CONTROL MODULE
UPSTREAM SCR NOX SENSOR
W/ PASSIVE
W/O PASSIVE
WASHER FLUID LEVEL SENSOR
WATER IN-FUEL SENSOR
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit (1 of 6) -> CHANGEOVER VALVE
