Wiring diagram awd relay (1 of 3)
-VE
AUTOMATIC TRANSMISSION FLUID PUMP
AWD FUSIBLE LINK
AWD RELAY
BCM-GWM ASSEMBLY
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
COMPUTER DATA LINES SYSTEM
GRN/ORG WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HS CAN H (PT)
HS CAN L (CH)
HS CAN L (PL)
HS CAN L (PT)
HS CANH (CH)
IGN
INSTRUMENT CLUSTER
O COMFORT SPLY CTRL
O IGN 3
PPL/GRY WIRE
REAR ENGINE JUNCTION BOX
REAR JUNCTION BOX
RED WIRE
TRANSFER CASE CONTROL MODULE
TRANSMISSION CONTROL MODULE
V BATT 1
YEL/RED WIRE
Go to component -> 2.0l turbo diesel, awd circuit -> AWD RELAY
Wiring diagram awd relay (2 of 3)
-VE
ABS CONTROL MODULE
AUTOMATIC TRANSMISSION FLUID PUMP
AWD FUSE
AWD RELAY
BATT SPLY
BCM-GWM ASSEMBLY
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
COMPUTER DATA LINES SYSTEM
GRN/ORG WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HS CAN H (PT)
HS CAN L (PT)
HS CAN-H
HS CAN-L
IGN
IGN SPLY
INSTRUMENT CLUSTER
O COMFORT SPLY CTRL
O IGN 3
PPL/GRY WIRE
REAR ENGINE JUNCTION BOX
REAR JUNCTION BOX
RED WIRE
TRANSFER CASE CONTROL MODULE
TRANSMISSION CONTROL MODULE
YEL/RED WIRE
Go to component -> 3.0l sc, awd circuit -> AWD RELAY
Wiring diagram awd relay (3 of 3)
2.0L TURBO DIESEL
ABS CONTROL MODULE
ABS VALVES FUSIBLE LINK
ACC FUSE
AWD FUSIBLE LINK
AWD RELAY
BLOWER RELAY
BLU/ORG WIRE
BLU/RED WIRE
BRN WIRE
BRN/GRN WIRE
BRN/RED WIRE
CENTRAL JUNCTION BOX
ENGINE CONTROL MODULE (ECM)
ENGINE CONTROL MODULE (ECM) RELAY
EPAS FUSIBLE LINK
ETS- TCM FUSE
FROM FRONT ENGINE JUNCTION BOX (DIAGRAM 1 OF 8)
FROM REAR JUNCTION BOX (DIAGRAM 7 OF 8)
FROM THROUGH PANEL STUD (DIAGRAM 1 OF 8)
FRONT BLOWER FUSIBLE LINK
FRONT FOG LAMP RELAY
FUSE 25
FUSE 9
FUSIBLE LINK 8
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRY WIRE
GRY/PPL WIRE
HCM FUSE
HEADLAMP WASH FUSE
HEATED WINDSHIELD RELAY
LEFT HEADLAMP
LEFT HEADLAMP WASH PUMP RELAY
LH AFS FUSE
N/A
ORG/WHT WIRE
PCM BATT FUSE
POWER STEERING CONTROL MODULE
PPL/GRY WIRE
PPL/RED WIRE
REAR BLOWER FUSIBLE LINK
REAR ENGINE JUNCTION BOX
RED WIRE
RH AFS FUSE
RIGHT HEADLAMP
SPARE FUSE
SPARE FUSIBLE LINK
STARTER PINION RELAY
STARTER RELAY
TO CENTRAL JUNCTION BOX (DIAGRAM 5 OF 8)
TRANSMISSION CONTROL MODULE
TRANSMISSION CONTROL SWITCH
WHT WIRE
WHT/PPL WIRE
WHT/RED WIRE
WIPER FAST- SLOW RELAY
WIPER ON/ OFF RELAY
WIPERS FUSIBLE LINK
YEL WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (4 of 8) -> AWD RELAY
