Jaguar F-Pace I (2016-2020) am/fm diversity antenna amplifier Wiring diagrams

This page contains all the electrical diagrams for the component. am/fm diversity antenna amplifier, in which he is found in the car Jaguar F-Pace I (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram am/fm diversity antenna amplifier (1 of 2)

Wiring diagram am/fm diversity antenna amplifier for Jaguar F-Pace I (2016-2020)

Get access

AM FM ANTENNA SCR AM FM ANTENNA SIG AM/FM DIVERSITY ANTENNA AMPLIFIER AMP WAKE UP ANTENNA 1 GND ANTENNA 1 SIG ANTENNA 2 GND ANTENNA 2 SIG ANTENNA 3 GND ANTENNA 3 SIG ANTENNA 4 GND ANTENNA 4 SIG ANTENNA AMPLIFIER (LEFT "C" PILLAR) BLK WIRE BLU WIRE BLUETOOTH ANT SIG BLUETOOTH ANT SHIELD WIFI ANT SIG BRN WIRE COAX COMPUTER DATA LINES SYSTEM DAB 1 SCREEN DAB 3 SCR DAB 3 SIG DABL/DAB 3 SHIELD DAB 1 SIG DABL/DAB 3 SIG FERRITE CORE FM ANTENNA AMPLIFIER FRONT BLUETOOTH ANTENNA FRONT OVERHEAD CONSOLE FRONT WIFI ANTENNA GPS ANT SIG SCR GPS ANT SHIELD GRY/PPL WIRE HS CAN-H HS CAN-L IMC GND INFOTAINMENT MASTER CONTROLLER (IMC) INTEGRATED CLIMATE CONTROL MODULE, SWITCHPACK LEFT TV ANTENNA AMPLIFIER LIN MIC - MIC 1 GND MIC 1+ MIC 2 GND MICROPHONE NCA WIRE ORG/ WIRE PPL/GRN WIRE RED WIRE SCN SCN A SDARS ANT SIG SCR SDARS ANT SHIELD SHIELD SIG SIG A SUB CAN H SUB CAN L TV, DIGITAL RADIO BAND 3 ANTENNA (LEFT "C" PILLAR) USB HUB GND USB HUB PWR VBATT W/ TELEMATICS W/O TELEMATICS W/ DIGITAL RADIO W/O DIGITAL RADIO WIFI ANT SHIELD YEL WIRE YEL/GRN WIRE YEL/GRY WIRE

Go to component: -> Navigation circuit, premium 17-speaker system (1 of 5) -> AM/FM DIVERSITY ANTENNA AMPLIFIER

Wiring diagram am/fm diversity antenna amplifier (2 of 2)

Wiring diagram am/fm diversity antenna amplifier for Jaguar F-Pace I (2016-2020)

Get access

AM FM ANTENNA SCR AM FM ANTENNA SIG AM/FM DIVERSITY ANTENNA AMPLIFIER AMP WAKE UP ANTENNA 1 GND ANTENNA 1 SIG ANTENNA 2 GND ANTENNA 2 SIG ANTENNA 3 GND ANTENNA 3 SIG ANTENNA 4 GND ANTENNA 4 SIG ANTENNA AMPLIFIER (LEFT "C" PILLAR) BLK WIRE BLU WIRE BLUETOOTH ANT SIG BLUETOOTH ANT SHIELD WIFI ANT SIG BRN WIRE COAX COMPUTER DATA LINES SYSTEM DAB 1 SCREEN DAB 3 SCR DAB 3 SIG DABL/DAB 3 SHIELD DAB 1 SIG DABL/DAB 3 SIG FERRITE CORE FM ANTENNA AMPLIFIER FRONT BLUETOOTH ANTENNA FRONT OVERHEAD CONSOLE FRONT WIFI ANTENNA GPS ANT SIG SCR GPS ANT SHIELD GRY/PPL WIRE HS CAN-H HS CAN-L IMC GND INFOTAINMENT MASTER CONTROLLER (IMC) INTEGRATED CLIMATE CONTROL MODULE, SWITCHPACK LEFT TV ANTENNA AMPLIFIER LIN MIC - MIC 1 GND MIC 1+ MIC 2 GND MICROPHONE NCA WIRE ORG/ WIRE PPL/GRN WIRE RED WIRE SCN SCN A SDARS ANT SIG SCR SDARS ANT SHIELD SHIELD SIG SIG A SUB CAN H SUB CAN L TV, DIGITAL RADIO BAND 3 ANTENNA (LEFT "C" PILLAR) USB HUB GND USB HUB PWR VBATT W/ TELEMATICS W/O TELEMATICS W/ DIGITAL RADIO W/O DIGITAL RADIO WIFI ANT SHIELD YEL WIRE YEL/GRN WIRE YEL/GRY WIRE

Go to component: -> Premium radio circuit, 17-speaker system (1 of 5) -> AM/FM DIVERSITY ANTENNA AMPLIFIER
