Jaguar F-Pace I (2016-2020) air conditioning pressure sensor Wiring diagram
This page shows the only wiring diagram for the component.air conditioning pressure sensor, which is found in the car Jaguar F-Pace I (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram air conditioning pressure sensor (1 of 1)
AIR CONDITIONING (A/C) COMPRESSOR SOLENOID
AIR CONDITIONING PRESSURE SENSOR
BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
CTRL
FRONT SUNLOAD SENSOR
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
LEFT FRONT FACE AIR DISTRIBUTION MOTOR
LEFT FRONT FEET AIR DISTRIBUTION MOTOR
LEFT REAR FACE AIR DISTRIBUTION MOTOR
LEFT REAR FACE DUCT AIR TEMPERATURE SENSOR
LEFT REAR FEET AIR DISTRIBUTION MOTOR
LEFT REAR TEMPERATURE BLEND MOTOR
LH SUNLOAD
LIN IN
LIN OUT
ORG/ WIRE
ORG/GRN WIRE
PPL
PPL/GRN WIRE
PPL/GRY WIRE
PPL/ORG WIRE
PPL/WHT WIRE
PWR
RH SUNLOAD
RIGHT REAR FACE DUCT AIR TEMPERATURE SENSOR
SIG
SOL +
V REF
WHT/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component: -> Automatic a/c circuit (3 of 6) -> AIR CONDITIONING PRESSURE SENSOR
