Starting circuit for Isuzu VehiCross I (1997-2001)
Starting circuit
AIR CONDITIONING SYSTEM
AUTOMATIC TRANSMISSION MODE SWITCH (UNDER VEHICLE, ON LEFT SIDE OF TRANSMISSION)
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
DASH FUSE BOX
FUSE 16 MAIN
FUSE CB-1 STARTER
FUSE/ RELAY BOX
IGNITION SWITCH
K-2 ANTI-THEFT, KEYLESS ENTRY CONTROL UNIT (LEFT OF STEERING COLUMN) START IN
LOCK OFF ON
RED WIRE
START OUT K-2
STARTER
STARTER MOTOR
STARTER RELAY
STARTER SOLENOID
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
