Shift interlock circuit for Isuzu VehiCross I (1997-2001)

Shift interlock circuit

Get access

BLK WIRE BLK/ORG WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BRAKE SWITCH (CLOSED WITH BRAKE PEDAL DEPRESSED) (ON BRAKE PEDAL SUPPORT) C-48 DASH FUSE BOX (BEHIND LEFT SIDE OF DASH) FUSE CB-13 STOP LIGHT FUSE CB-4 METER GENERATOR GRN WIRE GRN/ORG WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN ON OR START IGNITION BRAKE INPUT (NOT USED) BATTERY CHARGE SIG GROUND J-1 NOISE SUPPRESSOR FILTER 1 (BEHIND LEFT KICK PANEL) P-8 PARK POSITION SWITCH (CLOSED WITH GEAR SELECTOR IN PARK) (BELOW FRONT CONSOLE) RED WIRE RED/YEL WIRE SHIFT LOCK CONTROLLER (BELOW FRONT CONSOLE) SHIFT LOCK SOLENOID (BELOW FRONT CONSOLE) SOL CTRL + SOL CTRL - REF SIGNAL PARK INPUT VOLTAGE REGULATOR WHT WIRE WHT/GRN WIRE YEL WIRE
