Car Wiring Diagrams for Courtesy lamps circuit for Isuzu VehiCross I (1997-2001)

ANTI-THEFT AND KEYLESS ENTRY CONTROL UNIT BLK WIRE BLK/WHT WIRE C-32 DASH FUSE BOX (BEHIND LEFT DASH SIDE TRIM PANEL) DIODE BOX CB-25 DOME LIGHT GRN WIRE HOT AT ALL TIMES DOME LIGHT FUSE CB-6 K-2 L-1 L-2 LEFT DOOR SWITCH LEFT MAP LIGHT LEFT MAP LIGHT SWITCH MOMENTARY ON R-1 R-10 REAR VIEW MIRROR) RED WIRE RED/GRN WIRE RED/WHT WIRE RIGHT DOOR SWITCH RIGHT MAP LIGHT RIGHT MAP LIGHT SWITCH TIMER WARNING BUZZER WHT WIRE
