Exterior lamps circuit for Isuzu VehiCross I (1997-2001)

Exterior lamps circuit (1 of 2)

VehiCross Isuzu I (1997-2001): Exterior lamps circuit (1 of 2)

Get access

1 2 3 IGNITION OUTPUT GND BLK WIRE BRN WIRE BRN/WHT WIRE COMBINATION SWITCH DASH FUSE BOX (BEHIND LEFT SIDE OF DASH) FLASHER UNIT (ABOVE LEFT KICK PANEL) FUSE CB-15 BACK UP/ TURN LIGHT FUSE EB-1 HAZARD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT) GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE HAZARD HAZARD WARNING SWITCH HAZARD WARNING SWITCH LIGHT HOT AT ALL TIMES HOT IN ON LEFT LEFT FENDER MARKER LEFT FRONT COMBINATION LIGHT LEFT FRONT SIDE MARKER LEFT PARKING LIGHT LEFT TURN INDICATOR LIGHT METER ASSEMBLY OFF OFF HAZARD RED WIRE RIGHT RIGHT FENDER MARKER RIGHT FRONT SIDE MARKER RIGHT FRONT COMBINATION LIGHT RIGHT PARKING LIGHT RIGHT TURN INDICATOR LIGHT TURN SIGNAL SWITCH WHT WIRE

Exterior lamps circuit (2 of 2)

VehiCross Isuzu I (1997-2001): Exterior lamps circuit (2 of 2)

Get access

BLK WIRE BRAKE SWITCH (ON BRAKE PEDAL SUPPORT) COMBINATION SWITCH DASH FUSE BOX (BEHIND LEFT SIDE OF DASH) FUSE CB-13 STOP LIGHT FUSE CB-5 TAIL/ILLUM LIGHT GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HEAD PARK HEADLIGHT SWITCH HIGH MOUNTED STOP LIGHT 84 LED'S HOT AT ALL TIMES LEFT LICENSE LIGHT LEFT REAR SIDE MARKER LEFT TAILLIGHT ASSEMBLY NOISE SUPPRESSION FILTER 1 (BEHIND LEFT KICK PANEL) NOISE SUPPRESSION FILTER 2 (CENTER OF REAR ROOF PANEL) OFF RED WIRE RED/BLK WIRE RIGHT LICENSE LIGHT RIGHT REAR SIDE MARKER RIGHT TAILLIGHT ASSEMBLY TAIL STOP TAIL STOP TURN LIGHT TAIL/STOP LIGHT TAIL/STOP LIGHT TAILLIGHT RELAY (BEHIND LEFT KICK PANEL) TRANSMISSION, ANTI-LOCK BRAKES SYSTEMS TURN LIGHT WHT WIRE YEL WIRE
