Car Wiring Diagrams for Manual a/c circuit for Isuzu VehiCross I (1997-2001)

A/C COMPRESSOR A/C COMPRESSOR RELAY A/C COMPRESSOR RELAY CTRL A/C ON INPUT A/C SWITCH BLK WIRE BLU WIRE BRN WIRE BRN/YEL WIRE CLUTCH CONDENSER FAN (BEHIND RIGHT SIDE OF RADIATOR GRILLE) CONDENSER FAN RELAY EB-19 COND FAN FUSE FUSE/RELAY BOX (ON RIGHT SIDE OF ENGINE COMPARTMENT) GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRY/RED WIRE HEATER-A/C CONTROL PANEL HOT AT ALL TIMES LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE MICRO SWITCH (PART OF HEATER/ A/C CONTROL PANEL) OFF ORG/ WIRE PNK WIRE PNK/WHT WIRE POWERTRAIN CONTROL MODULE (PCM) (BELOW FRONT CONSOLE) THERMO PROTECTOR (OPENS WITH HIGH TEMPERATURE) THERMO SWITCH RELAY WHT WIRE YEL WIRE

A/C TRIPLE PRESSURE SWITCH (BEHIND LEFT SIDE OF RADIATOR GRILLE) ANTI-THEFT AND KEYLESS ENTRY CONTROL UNIT (LEFT OF STEERING COLUMN) BLK WIRE BLK/WHT WIRE BLOWER MOTOR (BELOW RIGHT SIDE OF DASH) BLOWER RESISTOR (BEHIND GLOVE BOX) BLU WIRE BLU/BLK WIRE BLU/RED WIRE BRN WIRE DASH FUSE BOX (BEHIND LEFT DASH TRIM PANEL) EB-16 MAIN FUSE EB-5 A/C FUSE EB-6 BLOWER FUSE EVAPORATOR TEMPERATURE SENSOR FAN CONTROL SWITCH FUSE FUSE/RELAY BOX (ON RIGHT SIDE OF ENGINE COMPARTMENT) GENERATOR GRN WIRE GRN/RED WIRE GRN/WHT WIRE HEATER-A/C CONTROL PANEL HEATER-A/C RELAY HOT AT ALL TIMES HOT IN START CB-1 ILLUM J/C LT GRN WIRE LT GRN/BLK WIRE OFF ORG/ WIRE PNK WIRE PNK/WHT WIRE RED WIRE STARTER CUT RELAY STARTING SYSTEM THERMO FUSE WHT WIRE WHT/GRN WIRE WHT/RED WIRE
