Isuzu VehiCross I (1997-2001) sol ctrl + sol ctrl - ref signal park input Wiring diagram
This page shows the only wiring diagram for the component.sol ctrl + sol ctrl - ref signal park input, which is found in the car Isuzu VehiCross I (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sol ctrl + sol ctrl - ref signal park input (1 of 1)
BLK WIRE
BLK/ORG WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRAKE SWITCH (CLOSED WITH BRAKE PEDAL DEPRESSED) (ON BRAKE PEDAL SUPPORT)
C-48
DASH FUSE BOX (BEHIND LEFT SIDE OF DASH)
FUSE CB-13 STOP LIGHT
FUSE CB-4 METER
GENERATOR
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION BRAKE INPUT (NOT USED) BATTERY CHARGE SIG GROUND
J-1
NOISE SUPPRESSOR FILTER 1 (BEHIND LEFT KICK PANEL)
P-8
PARK POSITION SWITCH (CLOSED WITH GEAR SELECTOR IN PARK) (BELOW FRONT CONSOLE)
RED WIRE
RED/YEL WIRE
SHIFT LOCK CONTROLLER (BELOW FRONT CONSOLE)
SHIFT LOCK SOLENOID (BELOW FRONT CONSOLE)
SOL CTRL + SOL CTRL - REF SIGNAL PARK INPUT
VOLTAGE REGULATOR
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> SOL CTRL + SOL CTRL - REF SIGNAL PARK INPUT
