Isuzu VehiCross I (1997-2001) reverse or l range output Wiring diagram

2 7 DATA LINK CONNECTOR (DLC) (LEFT SIDE OF DASH, NEAR ENGINE HOOD RELEASE) 6 C-43 ABS ACTIVE INPUT ABS INDICATOR LIGHT B-5 B-8 METER ASSEMBLY BLK WIRE BLU WIRE BLU/WHT WIRE BRAKE SWITCH (ON BRAKE PEDAL SUPPORT) C-1 DASH FUSE BOX (BEHIND LEFT SIDE OF DASH) ELECTRONIC BRAKE CONTROL MODULE (EBCM) (RIGHT REAR OF ENGINE COMPT.) FUSE CB-13 STOP LIGHT FUSE CB-16 ELEC IGN FUSE CB-4 METER FUSE EB-13 ABS FUSE EB-17 ABS FUSE/RELAY BOX (ON RIGHT SIDE OF ENGINE COMPT) G SENSOR - ABS (UNDER REAR OF CENTER CONSOLE) GND BATTERY BATTERY GROUND ABS IND LT CTRL DLC INPUT/OUTPUT GRN WIRE HOT AT ALL TIMES HOT IN ON OR START LEFT FRONT ABS SPEED SENSOR (INSIDE OF LEFT FRONT WHEEL) LEFT REAR ABS SPEED SENSOR (INSIDE OF LEFT REAR WHEEL) LT GRN/RED WIRE NOISE SUPPRESSION FILTER 1 ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/GRN WIRE ORG/WHT WIRE PNK OUTPUT C-44 WIRE POWERTRAIN CONTROL MODULE (PCM) (BEHIND FRONT CONSOLE) RED WIRE REVERSE OR L RANGE OUTPUT RIGHT FRONT ABS SPEED SENSOR (INSIDE OF RIGHT FRONT WHEEL) RIGHT REAR ABS SPEED SENSOR (INSIDE OF RIGHT REAR WHEEL) TORQUE ON DEMAND (TOD) CONTROL UNIT (BELOW RIGHT FRONT SEAT) VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE
