Isuzu VehiCross I (1997-2001) anti-theft and keyless entry control unit Wiring diagram
This page shows the only wiring diagram for the component.anti-theft and keyless entry control unit, which is found in the car Isuzu VehiCross I (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram anti-theft and keyless entry control unit (1 of 1)
ANTI-THEFT AND KEYLESS ENTRY CONTROL UNIT
BLK WIRE
BLK/WHT WIRE
C-32
DASH FUSE BOX (BEHIND LEFT DASH SIDE TRIM PANEL)
DIODE BOX CB-25
DOME LIGHT
GRN WIRE
HOT AT ALL TIMES DOME LIGHT FUSE CB-6
K-2
L-1
L-2
LEFT DOOR SWITCH
LEFT MAP LIGHT
LEFT MAP LIGHT SWITCH
MOMENTARY ON
R-1
R-10
REAR VIEW MIRROR)
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT DOOR SWITCH
RIGHT MAP LIGHT
RIGHT MAP LIGHT SWITCH
TIMER
WARNING BUZZER
WHT WIRE
Go to component -> Courtesy lamps circuit -> ANTI-THEFT AND KEYLESS ENTRY CONTROL UNIT
