Car Wiring Diagrams for Body computer circuits for Isuzu Trooper II (1992-2002)

ALARM, RELAY CONTROL UNIT (ABOVE RIGHT KICK PANEL) ANTI-THEFT SYSTEM BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE DASH FUSE BOX (BEHIND LEFT KICK PANEL) DEFOGGER ON/OFF REQUEST KEY IN IGNITION LIGHTS ON INPUT DEFOGGER SYSTEM DRIVER'S SEAT BELT SWITCH (IN DRIVER'S SEAT BELT BUCKLE) DRIVER'S SEAT BELT UNBUCKLED INPUT VARIBLE INTERMITTENT INPUT FUSE C-16 CLOCK (B) DOME LIGHT FUSE C-4 ELEC IGN FUSE C-6 FRT WIPER, WASHER FUSE C-6 RR WIPER, WASHER GRN/RED WIRE GRY/BLK WIRE GRY/GRN WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT IN ON OR START INTERMITTENT INPUT RUN/PARK INPUT KEY REMIND SWITCH LT BLU WIRE LT GRN/BLU WIRE LT GRN/RED WIRE LT GRN/WHT WIRE ORG/ WIRE ORG/BLU WIRE ORG/GRN WIRE PNK/BLU WIRE REAR WIPER SWITCH INPUT GROUND REAR WIPER SWITCH INPUT WINDSHIELD WASHER INPUT INTERMITTENT INPUT RED WIRE RED/WHT WIRE STARTER SWITCH WHT WIRE WHT/BLU WIRE WIPER/WASHER SYSTEM WIPER/WASHER SYSTEM WIPER/WASHER SYSTEM WIPER/WASHER SYSTEM WIPER/WASHER SYSTEM WIPER/WASHER SYSTEM
