Isuzu Trooper II (1992-2002) off lock switch Wiring diagram
This page shows the only wiring diagram for the component.off lock switch, which is found in the car Isuzu Trooper II (1992-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off lock switch (1 of 1)
5 D-30 1 D-5
AUTO
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
C-18 DOOR LOCK FUSE
C-4 ELEC. IGN. FUSE
C/B-2 (P/W, P/S, S/R) CB
CONTROL UNIT)
D-5
DASH FUSE BOX (BEHIND LEFT KICK PANEL)
DOWN RELAY
HOT AT ALL TIMES
HOT IN ON OR START
LEFT FRONT DOOR POWER WINDOW, LOCK SWITCH
LEFT FRONT POWER WINDOW MOTOR (IN FRONT OF DOOR)
LEFT FRONT POWER WINDOW SWITCH DN
LEFT REAR POWER WINDOW MOTOR (IN FRONT OF DOOR)
LEFT REAR POWER WINDOW SWITCH
LEFT REAR POWER WINDOW SWITCH DN
LT GRN WIRE
LT GRN/WHT WIRE
NOT USED
OFF
OFF LOCK SWITCH
POWER TOPS SYSTEM
POWER WINDOW RELAY
POWER WINDOW SWITCH
RED/YEL WIRE
RIGHT FRONT DOOR POWER WINDOW, LOCK SWITCH
RIGHT FRONT POWER WINDOW MOTOR (IN FRONT OF DOOR)
RIGHT FRONT POWER WINDOW SWITCH DN
RIGHT REAR POWER WINDOW MOTOR (IN FRONT OF DOOR)
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR POWER WINDOW SWITCH DN
UP RELAY
WHT WIRE
YEL WIRE
Go to component -> Power window circuit -> OFF LOCK SWITCH
